Swift

Getting Started

Installation

  • Frameworks

  • Cocoapods

  • Carthage

iOS & tvOS

  1. Download Couchbase Lite for the platform your app is targeting.

  2. Unzip the file.

  3. Open the Couchbase Lite folder and drag CouchbaseLite.framework to the project navigator in Xcode.

  4. In the Choose options for adding these files sheet, make sure that your app target is selected.

Couchbase Lite requires additional frameworks and libraries for building an app. These additional dependencies are added via Xcode build settings.

  1. In the Xcode navigator, click on the project open the Build Settings tab.

  2. Scroll to the Linking section, find the Other Linker Flags row and then add the flag -ObjC (be sure to use the capitalization shown).

  3. Click the Build Phases tab.

  4. Expand the Link Binary With Libraries section and add the following items.

    CFNetwork.framework
    Security.framework
    SystemConfiguration.framework
    libsqlite3.dylib
    libz.dylib
    libc++.dylib

    To use the SDK in Swift files, you must also import the framework in a bridging header (#import <CouchbaseLite/CouchbaseLite.h>).

macOS

For a macOS target, you’ll need to make sure the framework is copied to your app’s bundle. Follow the steps below.

  1. Download Couchbase Lite for the platform your app is targeting.

  2. Open the Build Settings tab of your app target’s settings.

  3. In the Linking section, edit Runpath Search Paths and add @loader_path/../Frameworks/.

  4. Now switch to the Build Phases.

  5. Press the Add Build Phase button at the top of the window and create a new Copy Files phase.

    ios copy files phase
  6. Set the phase’s destination to Frameworks.

  7. Press the + button below the phases' file list and select CouchbaseLite.framework to add it.

Available frameworks

Framework Service

CouchbaseLiteListener.framework

To access the database through HTTP (often used for hybrid development and peer-to-peer sync). This component has a dependency on JavaScriptCore.framework, make sure to add this framework as well if you’re planning on using it.

CBLJSONValidator

Validates JSON objects against JSON-Schema specs.

CBLRegisterJSViewCompiler, libCBLJSViewCompiler.a

To register Views and Filters through the Listener. When doing so, the logic is written in JavaScript and stored in the database.

libCBLForestDBStorage.a

To use ForestDB as the storage type.

libsqlcipher.a

To enable encryption on SQLite databases.

Extras/CBLEncryptionController

Utility class to handle password entry. Prompts the user to make up a key, asks for the key when re-opening the database, and asks again if the key was incorrect It even takes advantage of Touch ID fingerprint authentication on recent iOS devices to avoid making the user deal with a password at all.

Extras/CBLIncrementalStore

A subclass of the NSIncrementalStore to allow Core Data to use a Couchbase Lite database as its persistent storage instead of the default SQLite database.

Extras/CBLUICollectionSource

A UICollectionView data source driven by a CBLLiveQuery.

  1. Install Cocoapods

  2. In your Podfile, add the following.

    pod 'couchbase-lite-ios', '~> 1.4.1'
  3. Install the pods and open the .xcworkspace file generated by Cocoapods.

    pod install

    To use the SDK in Swift files, you must also import the framework in a bridging header (#import <CouchbaseLite/CouchbaseLite.h>).

    The following subspecs are available to import different Couchbase Lite components.

    Pod Service

    couchbase-lite-ios/SQLite

    To use SQLite as the storage type. This is the default.

    couchbase-lite-ios/SQLCipher

    To use SQLCipher as the storage type.

    couchbase-lite-ios/ForestDB

    To use ForestDB as the storage type.

  1. Install Carthage

  2. Add github "couchbase/couchbase-lite-ios" "release/1.4.1" to your Cartfile.

  3. Run carthage update --platform ios.

  4. Drag CouchbaseLite.framework from the appropriate platform directory in Carthage/Build/ to the Embedded Binaries section of your Xcode project’s General settings.

Starter Code

Create a new Xcode project and install Couchbase Lite by following one of the methods above.

xcode installation

Open ViewController.swift in Xcode.

If you installed Couchbase Lite with Carthage, append the following in your import section.

import CouchbaseLite

Then, add the following in the viewDidLoad method.

// Create a manager
let manager = CBLManager.sharedInstance()

let database: CBLDatabase
do {
 // Create or open the database named app
 database = try manager.databaseNamed(app)
} catch {
 print(Database creation or opening failed)
 return
}

// The properties that will be saved on the document
let properties = [title: Couchbase Mobile, sdk: iOS]
// Create a new document
let document: CBLDocument = database.createDocument()

do {
 // Save the document to the database
 try document.putProperties(properties)
} catch {
 print(Can't save document in database)
 return
}

// Log the document ID (generated by the database)
// and properties
print(Document ID :: \(document.documentID))
print(Learning \(document.property(forKey: sdk)!))

// Create replicators to push  pull changes to  from Sync Gateway
let url = URL(string: http://localhost:4984/hello)!
let push = database.createPushReplication(url)
let pull = database.createPullReplication(url)
push.continuous = true
pull.continuous = true

// Start replicators
push.start()
pull.start()

Build and run. You should see the document ID and property printed to the console. The document was successfully persisted to the database.

xcode running

Before synchronizing documents to Sync Gateway you will need to disable App Transport Security. In the Xcode navigator, right-click on Info.plist and open it as a source file.

info plist

Append the following inside of the dict XML tags to disable ATS.

keyNSAppTransportSecurity/key
dict
keyNSAllowsArbitraryLoads/keytrue/
/dict

The application is now correctly configured to start synchronizing documents with Sync Gateway.

Manager

A Manager is the top-level object that manages a collection of Couchbase Lite Database instances. You need to create a Manager instance before you can work with Couchbase Lite objects in your Application.

Creating a manager

You create a Manager object by calling a constructor or initializer on the Manager class.

let manager = CBLManager.sharedInstance()
if manager == nil {
    NSLog("Cannot create Manager Instance")
}

Dude, where’s my database file?

The Manager creates a directory in the filesystem and stores databases inside it. Normally, you don’t need to care where that is — your application shouldn’t be directly accessing those files. But sometimes it does matter.

  • Android: The directory is the location returned by the Android Context object’s getFilesDir().

  • iOS: Application Support/CouchbaseLite/

  • macOS: ~/Library/Application Support/com.example.YourAppBundleID/CouchbaseLite/

One notable case where the location can be important is on iOS: Apple’s app review process tries to make sure that the only application data that will be backed up to iCloud is data created by the user. So it’s a red flag when, on first launch, an app creates data in backed-up locations (including the Documents and Application Support directories) without user action. Unfortunately, that will happen if your app starts a pull replication on launch, or installs a pre-populated database. Some apps using Couchbase Lite have had their App Store approval held up for this reason!

On iOS or Mac OS you can change the location of the databases by instantiating the Manager via a constructor/initializer that takes a path as a parameter. This directory will be created if it doesn’t already exist. (Of course you should be consistent about what path to use, since if you change the path the application won’t be able to find any already-existing databases.)

On Android, you can subclass com.couchbase.lite.android.AndroidContext and override its getFilesDir method to return the desired directory.

let dir = WhereIWantCBLStuffToGo()
var error: NSError?
self.manager = CBLManager(directory: dir, options: nil, error: &error)
if manager == nil {
    NSLog("Cannot create Manager instance: %@", (error ?? ""))
}

Global logging settings

You can customize the global logging settings for Couchbase Lite via the Manager class. Log messages are tagged, allowing them to be logically grouped by activity. You can control whether individual tag groups are logged.

The available tags are:

In Swift tag groups is disabled by default.

BLIP
BLIPVerbose
CBLDatabase
CBLJSONMatcher
CBLListener
CBLListenerVerbose
CBLModel
CBL_Router
CBL_Server
CBL_URLProtocol
CBLValidation
CBLRemoteRequest
CBLMultiStreamWriter
ChangeTracker
ChangeTrackerVerbose
JSONSchema
MYDynamicObject
Query
RemoteRequest
Sync
SyncVerbose
View
ViewVerbose
WS

The following code snippet enables logging for the Sync tag.

CBLManager.enableLogging("Sync")

Concurrency Support

In Java all Couchbase Lite objects may be shared freely between threads. The rest of this section is irrelevant for Java programs, and applies only to Objective-C.

In Objective-C, a Manager instance and the object graph associated with it may only be accessed from the thread or dispatch queue that created the Manager instance. Concurrency is supported through explicit method calls.

Running individual blocks in the background

You can use the CBLManager method backgroundTellDatabaseNamed:to: to perform any operation in the background. Be careful with this, though! Couchbase Lite objects are per-thread, and your block runs on a background thread, so:

  • You can’t use any of the Couchbase Lite objects (databases, documents, models…​) you were using on the main thread. Instead, you have to use the CBLDatabase object passed to the block, and the other objects reachable from it.

  • You can’t save any of the Couchbase Lite objects in the block and then call them on the main thread. (For example, if in the block you allocated some CBLModels and assigned them to properties of application objects, bad stuff would happen if they got called later on by application code.)

  • And of course, since the block is called on a background thread, any application or system APIs you call from it need to be thread-safe.

In general, it’s best to do only very limited things using this API, otherwise it becomes too easy to accidentally use main-thread Couchbase Lite objects in the block, or store background-thread Couchbase Lite objects in places where they’ll be called on the main thread.

Here’s an example that deletes a number of documents given an array of IDs:

// "myDB" is the CBLDatabase object in use on the main thread.
let mgr = myDB.manager
let name = myDB.name
mgr.backgroundTellDatabaseNamed(name, to: { (bgdb: CBLDatabase!) -> Void in
  // Inside this block we can't use myDB; instead use the instance given (bgdb)
  for docID in docIDs {
    bgdb.documentWithID(docID).deleteDocument(nil)
  }
})

Running Couchbase Lite on a background thread

If you want to do lots of Couchbase Lite processing in the background in Objective-C, the best way to do it is to start your own background thread and use a new Manager instance on it.

func application(application: UIApplication, didFinishLaunchingWithOptions launchOptions: NSDictionary?) -> Bool {
  let manager = CBLManager.sharedInstance()
  var error: NSError?
  let database = manager.databaseNamed("db", error: &error)
  let bgMgr = manager.copy()
  NSThread.detachNewThreadSelector("runBackground:", toTarget: self, withObject: bgMgr)
  return true
}
func runBackground(bgMgr: CBLManager) {
  var error: NSError?
  let bgDB = [bgMgr.databaseNamed("db", error: &error)]
}

If you don’t plan to use Couchbase Lite on the main thread at all, the setup is even easier. Just have the background thread create a new instance of CBLManager from scratch and use that:

func application(application: UIApplication, didFinishLaunchingWithOptions launchOptions: NSDictionary?) -> Bool {
  // We're not going to use Couchbase Lite at all on the main thread;
  // instead we start a background thread to run it on:
  NSThread.detachNewThreadSelector("runBackground", toTarget: self, withObject: nil)
  return true
}
func runBackground {
  let manager = CBLManager.sharedInstance()
  var error: NSError?
  let db = [manager.databaseNamed("db", error: &error)]
  // ... now use the database
}

Database

A Database is a container and a namespace for documents, a scope for queries, and the source and target of replication. Databases are represented by the Database class.

Most applications only need one database, but you can use the Manager to create as many as you need. Multiple databases are independent of each other. If your application supports switching between multiple users, each with their own separate content and settings, you should consider using a database for each user. Otherwise, it’s usually best to stick with one database.

A database is not a table. Couchbase Lite doesn’t have any equivalent of relational database tables: different types of documents all coexist in the same database. Usually you use a "type" property to distinguish them.

A database has the following elements:

  • Its name. The name must consist only of lowercase ASCII letters, digits, and the special characters _$()+-/. It must also be less than 240 bytes and start with a lower case letter.

  • Documents. Each document is identified uniquely by its ID.

  • Views. Each view has a unique name, and a persistent index as well as map and reduce functions.

  • Filter functions. These are used to replicate subsets of documents.

  • Replications. Each replication specifies a remote database to sync documents to or from, and other parameters.

Creating a database

Creating an empty database

You create a new empty database by simply accessing it, using the databaseNamed method — this method opens the database if it isn’t yet open, and creates it if it doesn’t yet exist. See the next section, Opening a database, for details. This way you don’t have to write any special code for the first launch of the app.

Pulling down a remote database

Often you’ll want to create a local clone (or subset) of a database on a server. To do this you simply create an empty database as above, then start a pull replication that will download the remote database into it. The replication is asynchronous, but you can monitor its progress to find out when it’s done.

If possible, avoid blocking until the replication completes. The user’s first-launch experience will be much more pleasant if s/he can begin using your app immediately instead of staring at a modal progress screen waiting for downloads to complete. If you’ve implemented a data-driven UI, the content will appear incrementally as it downloads. For example, the ToDoLite app initially displays no content, but the to-do lists and their items quickly appear as the replication progresses.

Installing a pre-built database

If your app needs to sync a lot of data initially, but that data is fairly static and won’t change much, it can be a lot more efficient to bundle a database in your application and install it on the first launch. Even if some of the content changes on the server after you create the app, the app’s first pull replication will bring the database up to date.

This is essentially trading setup time for app installation time. If you install a 100MB database in your app, that of course adds to the time it takes to download and install the app. But it can still be faster than replication since the 100MB database will simply be downloaded in bulk as part of the app archive, instead of going through the interactive sync protocol. Also, the download happens when the user expects it to (while installing the app) rather than when s/he’s not (on first launch).

To use a prebuilt database, you need to set up the database, build the database into your app bundle as a resource, and install the database during the initial launch.

Setting Up the Database: You need to make the database as small as possible. Couchbase Lite keeps a revision history of every document and that takes up space. When creating the database locally, you can make it smaller by storing each document (via a PUT request) only once, rather than updating it multiple times. (You can double-check this by verifying that each document revision ID starts with 1-.)

If you start with a snapshot of a live database from a server, then create a new, empty local database and replicate the source database into it.

On iOS / Mac OS, the Couchbase Lite Xcode project has a target called LiteServ that builds a small Mac app that does nothing but run the REST API. LiteServ is a useful tool for creating databases and running replications locally on your development machine.

Extracting and Building the Database: Next you need to find the database’s files. The location of these is determined by the Manager instance; it’s in a directory called CouchbaseLite whose default location is platform-specific. (On iOS and Mac OS, it’s in the Application Support directory.) The main database file has a .cblite extension. If your database has attachments, you also need the "databasename attachments" directory that’s adjacent to it.

iOS/Mac specific instructions: Add the database file and the corresponding attachments directory to your Xcode project. If you add the attachments folder, make sure that in the Add Files sheet you select the Create folder references for any added folders radio button, so that the folder structure is preserved; otherwise, the individual attachment files are all added as top-level bundle resources.

Installing the Database: After your app launches and creates a Database instance for its database, it needs to check whether the database exists. If the database does not exist, the app should copy it from the app bundle. The code looks like this:

let dbManager = CBLManager.sharedInstance()
var error :NSError?
var database = dbManager.existingDatabaseNamed("catalog", error: &error)
if database == nil {
    let cannedDbPath = NSBundle.mainBundle().pathForResource("catalog", ofType: "cblite")
    let cannedAttPath = NSBundle.mainBundle().pathForResource("catalog attachments", ofType: "")
    dbManager.replaceDatabaseNamed("catalog", withDatabaseFile: cannedDbPath, withAttachments: cannedAttPath, error: &error)
    if error != nil {
        self.handleError(error)
    }
    database = dbManager.existingDatabaseNamed("catalog", error: &error)
    if error != nil {
        self.handleError(error)
    }
}

Opening a database

You’ll typically open a database while initializing your app, right after instantiating the Manager object, and store a reference to the Database object as either a global variable or a property of your top-level application object (the app delegate on iOS or Mac OS). Opening a database is as simple as calling the Manager’s databaseNamed method — this will first create a new empty database if one doesn’t already exist with that name. It’s fine to call this method more than once: it will return the same Database instance every time.

For compatibility reasons, database names cannot contain uppercase letters! The only legal characters are lowercase ASCII letters, digits, and the special characters _$()+-/
let manager = CBLManager.sharedInstance()
var error: NSError?
self.database = manager.databaseNamed("my-database", error: &error)
if self.database == nil {
    self.handleError(error)
}
If you want to open only an existing database, without the possibility of creating a new one, call the related Manager method existingDatabaseNamed instead. It returns null/nil (without an error or exception) if no database with that name exists.

Database encryption

Since Couchbase Lite 1.2, databases can be encrypted using SQLCipher; an open source extension to SQLite that provides transparent encryption of database files. The encryption specification is 256-bit AES. The steps below outline how to enable it.

Step 1: Installing SQLCipher

SQLCipher is an optional dependency. The section below describes how to add it on each platform.

iOS
  1. Download the iOS SDK from here.

  2. Add the libsqlcipher.a library to your XCode project.

  3. Go to the Link Binary With Libraries build phase of your app target.

  4. Remove libsqlite.dylib

Step 2: Enabling encryption

At this point, Couchbase Lite won’t work any differently. Databases are still unencrypted by default. To enable encryption, you must register an encryption key when opening the database with the openDatabase method.

var options: CBLDatabaseOptions = CBLDatabaseOptions()
options.storageType = "SQLite"
options.encryptionKey = "password123456"
options.create = true
var database: CBLDatabase = manager.openDatabaseNamed("db", withOptions: options, error: nil)

If the database does not exist (and options.create is true) it will be created encrypted with the given key.

If the database already exists, the key will be used to decrypt it (and to encrypt future changes). If the key does not match the one previously used, opening the database will fail; the error/exception will have status code 401.

To change the encryption key, you must first open the database using the openDatabase method with the existing key and if the operation is successful, use the changeEncryptionKey method providing the new key. Passing nil as the value will disable encryption.

Storage engines

The following section describes how to set up ForestDB, which will be deprecated in the next major release of Couchbase Mobile. For present and future development, we recommend to use the default storage type, SQLite.

There are two storage engines available with Couchbase Lite: SQLite and ForestDB. In the case of SQLite, it will use the system dependency already available on most platforms (iOS, Android, Windows…​). To use ForestDB, the project must include the ForestDB storage dependency (see instructions below).

What is ForestDB?

ForestDB is a persistent key-value storage library, it’s a key-value map where the keys and values are binary blobs.

Benefits of using ForestDB
  • Faster (2x to 5x as fast, depending on the operation and data set)

  • Better concurrency (writers never block readers)

  • Lower RAM footprint (data caches are shared between threads)

  • Database compaction is automatic and runs periodically in the background

iOS

The ForestDB engine isn’t built into the iOS and tvOS platforms, to save space. To use ForestDB on those platforms you’ll need to link it into your app as an extra static library.

  1. Add the library libCBLForestDBStorage.a to your project and add it to your iOS app target’s "Link Binary With Libraries" build phase.

  2. Link the system library libc++.dylib. To do that, in the target’s Build Phases editor, press the "+" button below the "Link Binary With Libraries" and add libc++.dylib

  3. Make sure -ObjC is set in Other Linker Flags in Build Settings

These steps aren’t necessary for Mac OS because that version of the Couchbase Lite framework already has ForestDB built into it.

Choosing a storage engine

For new databases

At runtime, you need to tell the Manager you want to use ForestDB, by setting its storageType to ForestDB.

manager.storageType = kCBLForestDBStorage

This only applies to new databases. Existing local database files will always open with the same storage engine that created them.

Upgrading databases to ForestDB

It’s possible to upgrade an existing local database file from SQLite to ForestDB. You can use this option if you have an already-shipping app and want your existing installs to use ForestDB as well as new installs. To do this, you use an alternate method to open your database, one that allows you to specify a set of options.

var options: CBLDatabaseOptions = CBLDatabaseOptions()
options.create = true
options.storageType = kCBLForestDBStorage  // Forces upgrade to ForestDB
var db: CBLDatabase = manager.openDatabaseNamed("my-database", withOptions: options, error: error!)

Setting the options' storageType property forces the database to use the ForestDB format. If it’s currently in SQLite format, it will be converted in place before being opened. (The next time, it will just open normally, since it’s already ForestDB.)

Concurrency support

Concurrency support varies by platform.

iOS, Mac OS (Objective-C)

The Objective-C implementation follows the typical behavior of Cocoa classes: the classes are not themselves thread-safe, so the app is responsible for calling them safely. In addition, some of the classes post NSNotifications and need to know what runloop or dispatch queue to deliver the notifications on. Therefore, each thread or dispatch queue that you use Couchbase Lite on should have its own set of Couchbase Lite objects.

If your app uses Couchbase Lite on multiple threads, then on each thread (or dispatch queue) it must:

  • Create a new CBLManager instance. If you use multiple threads, do not use the sharedInstance.

  • Use only objects (Databases, Documents, …​) acquired from its Manager.

  • Not pass any Couchbase Lite objects to code running on any other thread/queue.

If different threads/queues need to communicate to each other about documents, they can use the document ID (and database name, if you use multiple databases).

By default, Couchbase Lite is thread-based; if you are instead creating a CBLManager for use on a dispatch queue (which might run on different threads during its lifetime), you must set the Manager’s dispatchQueue property, so that it can properly schedule future calls.

As a convenience, CBLManager’s backgroundTellDatabaseNamed:to: method will run a block on an existing background thread (the same one the replicator runs on). You must be careful to avoid using any of the calling thread’s objects in the block, since the block runs on a different thread. Instead, you should use the CBLDatabase object passed to the block and derive other objects like documents from it.

// Example to read a document asynchronously on a background thread.
// (This isn't very realistic since reading one document is fast enough to
// do on the main thread.)
let docID = myDocument.documentID
myDB.manager.backgroundTellDatabaseNamed(myDB.name, to: { (bgdb: CBLDatabase!) -> Void in
    if let bgDoc = bgdb[docID] {
        var properties = bgDoc.properties;
        dispatch_async(nil, { () -> Void in
            self.handleDoc(properties)
        })
    }
})
Android, Java

It is safe to call Couchbase Lite from multiple threads on the Android / Java platform. If you find any thread safety related issues, please report a bug.

Database notifications

You can register for notifications when documents are added/updated/deleted from a database. In practice, applications don’t use these as much as live queries and document change notifications; still this facility can be useful if you want a lightweight way to tell whenever anything’s changed in a database.

NSNotificationCenter.defaultCenter().addObserverForName(kCBLDatabaseChangeNotification, object: myDatabase, queue: nil) {
  (notification) -> Void in
    if let changes = notification.userInfo!["changes"] as? [CBLDatabaseChange] {
        for change in changes {
            NSLog("Document changed, revision ID '%@'", change.revisionID)
        }
    }
}

The example above shows how to access the revision linked to the document change that is being processed. The notifications may not be delivered immediately after the document changes. Notifications aren’t delivered during a transaction; they’re buffered up for delivery after the transaction completes.

Database housekeeping

Refer to the Revision guide to learn about compaction and pruning to manage the database size.

Deleting a database

The delete method (deleteDatabase in Objective-C) permanently deletes a database’s file and all its attachments. After this, you should immediately set your Database reference to nil/null and not call it again.

var error: NSError?
if !self.database.deleteDatabase(&error) {
    self.handleError(error)
}
self.database = nil

Document

In a document database such as Couchbase Lite, the primary entity stored in a database is called a document instead of a "row" or "record". This reflects the fact that a document can store more data, with more structure, than its equivalent in other databases.

In Couchbase Lite, a document’s body takes the form of a JSON object — a collection of key/value pairs where the values can be different types of data such as numbers, strings, arrays or even nested objects. Every document is identified by a document ID, which can be automatically generated (as a UUID) or determined by the application; the only constraints are that it must be unique within the database, and it can’t be changed.

In addition, a document can contain attachments, named binary blobs that are useful for storing large media files or other non-textual data. Couchbase Lite supports attachments of unlimited size, although the Sync Gateway currently imposes a 20MB limit for attachments synced to it.

Couchbase Lite keeps track of the change history of every document, as a series of revisions. This is somewhat like a version control system such as Git or Subversion, although its main purpose is not to be able to access old data, but rather to assist the replicator in deciding what data to sync and what documents have conflicts. Every time a document is created or updated, it is assigned a new unique revision ID. The IDs of past revisions are available, and the contents of past revisions may be available, but only if the revision was created locally and the database has not yet been compacted.

To summarize, a document has the following attributes:

  • A document ID

  • A current revision ID (which changes every time the document is updated)

  • A history of past revision IDs (usually linear, but will form a branching tree if the document has or has had conflicts)

  • A body in the form of a JSON object, i.e., a set of key/value pairs

  • Zero or more named binary attachments

  • Creating, Reading, Updating and Deleting documents (CRUD)

Creating, Reading, Updating and Deleting documents (CRUD)

Couchbase Lite of course supports the typical database "CRUD" operations on documents: Create, Read, Update, Delete.

Creating documents

You can create a document with or without giving it an ID. If you don’t need or want to define your own ID, call the Database method createDocument, and the ID will be generated randomly in the form of a Universally Unique ID (UUID), which looks like a string of hex digits. The uniqueness ensures that there is no chance of an accidental collision by two client apps independently creating different documents with the same ID, then replicating to the same server.

The following example shows how to create a document with an automatically-assigned UUID:

let owner = "profile".stringByAppendingString(userId)
let properties = [
    "type": "list",
    "title": title,
    "owner": owner,
    "members": []
]
let document = database.createDocument()
var error: NSError?
if document.putProperties(properties, error: &error) == nil {
    self.handleError(error)
}

If you do want to choose the document’s ID, just call the Database method getDocument, just as you would to retrieve an existing document. If the document doesn’t exist yet, you still get a valid Document object, it just doesn’t have any revisions or contents yet. The first time you save the document, it will be added persistently to the database. If a document does already exist with the same ID, saving the document will produce a conflict error.

The following example shows how to create a document with an custom ID:

let properties =
[
    "title": "Little, Big",
    "author": "John Crowley",
    "published":  1982
]
let document = database.documentWithID("978-0061120053")
var error: NSError?
if document.putProperties(properties, error: &error) == nil {
    self.handleError(error)
}
It’s up to you whether to assign your own IDs or use random UUIDs. If the documents are representing entities that already have unique IDs — like email addresses or employee numbers — then it makes sense to use those, especially if you need to ensure that there can’t be two documents representing the same entity. For example, in a library cataloging app, you wouldn’t want two librarians to independently create duplicate records for the same book, so you might use the book’s ISBN as the document ID to enforce uniqueness.

Reading documents

To retrieve a Document object given its ID, call the Database method getDocument. As described in the previous section, if there is no document with this ID, this method will return a valid but empty Document object. (If you would rather get a null/nil result for a nonexistent document, call existingDocumentWithID instead.)

Document objects, like document IDs, are unique. That means that there is never more than one Document object in memory that represents the same document. If you call getDocument multiple times with the same ID, you get the same Document object every time. This helps conserve memory, and it also makes it easy to compare Document object references (pointers) — you can just use == to check whether two references refer to the same document.

Loading a Document object doesn’t immediately read its properties from the database. Those are loaded on demand, when you call an accessor method like getProperties (or access the Objective-C property properties). The properties are represented using whatever platform type is appropriate for a JSON object. In Objective-C they’re an NSDictionary, in Java a Map<String,Object>.

Here’s a simple example of getting a document’s properties:

let doc = database.documentWithID(myDocID)
// We can directly access properties from the document object:
let title = doc["title"] as? String
// Or go through its properties dictionary:
let properties = doc.properties;
let owner = properties["owner"] as? String;
The getProperties method is actually just a convenient shortcut for getting the Document’s currentRevision and then getting its properties — since a document usually has multiple revisions, the properties really belong to a revision. Every existing document has a current revision (in fact that’s how you can tell whether a document exists or not). Almost all the time you’ll be accessing a document’s current revision, which is why the convenient direct properties accessor exists.

Updating documents

There are two methods that update a document: putProperties and update. We’ll cover them both, then explain why they’re different.

putProperties is simpler: given a new JSON object, it replaces the document’s body with that object. Actually what it does is creates a new revision with those properties and makes it the document’s current revision.

let doc = database.documentWithID(myDocID)
var properties = doc.properties
properties["title"] = title
properties["notes"] = notes
var error: NSError?
if doc.putProperties(properties, error: &error) == nil {
    self.handleError(error)
}

update instead takes a callback function or block (the details vary by language). It loads the current revision’s properties, then calls this function, passing it an UnsavedRevision object, whose properties are a mutable copy of the current ones. Your callback code can modify this object’s properties as it sees fit; after it returns, the modified revision is saved and becomes the current one.

let doc = database.documentWithID(myDocID)
var error: NSError?
doc.update({ (newRev) -> Bool in
    newRev["title"] = title
    newRev["notes"] = notes
    return true
}, error: &error)
if error != nil {
    self.handleError(error)
}

Whichever way you save changes, you need to consider the possibility of update conflicts. Couchbase Lite uses Multiversion Concurrency Control (MVCC) to guard against simultaneous changes to a document. (Even if your app code is single-threaded, the replicator runs on a background thread and can be pulling revisions into the database at the same time you’re making changes.)

Here’s the typical sequence of events that creates an update conflict:

  1. Your code reads the document’s current properties, and constructs a modified copy to save

  2. Another thread (perhaps the replicator) updates the document, creating a new revision with different properties

  3. Your code updates the document with its modified properties

Clearly, if your update were allowed to proceed, the change from step 2 would be overwritten and lost. Instead, the update will fail with a conflict error. Here’s where the two API calls differ:

  1. putProperties simply returns the error to you to handle. You’ll need to detect this type of error, and probably handle it by re-reading the new properties and making the change to those, then trying again.

  2. update is smarter: it handles the conflict error itself by re-reading the document, then calling your block again with the updated properties, and retrying the save. It will keep retrying until there is no conflict.

Of the two techniques, calling update may be a bit harder to understand initially, but it actually makes your code simpler and more reliable. We recommend it. (Just be aware that your callback block can be called multiple times.)

Deleting documents

The delete method (deleteDocument: in Objective-C) deletes a document:

let doc = database.documentWithID(myDocID)
var error: NSError?
if !doc.deleteDocument(&error) {
    self.handleError(error)
}

Deleting a document actually just creates a new revision (informally called a "tombstone") that has the special _deleted property set to true. This ensures that the deletion will replicate to the server, and then to other endpoints that pull from that database, just like any other document revision.

It’s possible for the delete call to fail with a conflict error, since it’s really just a special type of putProperties. In other words, something else may have updated the document at the same time you were trying to delete it. It’s up to your app whether it’s appropriate to retry the delete operation.

If you need to preserve one or more fields in a document that you want to delete (like a record of who deleted it or when it was deleted) you can avoid the delete method; just update the document and set the UnsavedRevision's `deletion property to true, or set JSON properties that include a "_deleted" property with a value of true. You can retain all of the fields, as shown in the following example, or you can remove specified fields so that the tombstone revision contains only the fields that you need.

doc.update({ (newRev) -> Bool in
    newRev.isDeletion = true
    newRev["deleted_at"] = currentTimeString
    return true
}, error: &error)
if error != nil {
    self.handleError(error)
}

Document expiration (TTL)

Documents in a local database can have an expiration time. After that time, they are automatically purged from the database - this completely removes them, freeing the space they occupied. This feature was introduced in Couchbase Lite 1.3.

The following example sets the TTL for a document to 5 seconds from the current time.

var ttl = NSDate(timeIntervalSinceNow: 5)
var properties = ["foo": "bar"]
var doc = db.createDocument()
doc.putProperties(properties, error: nil)
doc.expirationDate = ttl

Expiration timing is not highly precise. The times are stored with one-second granularity, and the timer that triggers expiration may be delayed slightly by the operating system or by other activity on the database thread. Expiration won’t happen while the app is not running; this means it may be triggered soon after the app is activated or launched, to catch up with expiration times that have already passed.

As with the existing explicit purge mechanism, this applies only to the local database; it has nothing to do with replication. This expiration time is not propagated when the document is replicated. The purge of the document does not cause it to be deleted on any other database. If the document is later updated on a remote database that the local database pulls from, the new revision will be pulled and the document will reappear.

Document change notifications

You can register for notifications when a particular document is updated or deleted. This is very useful if you’re display a user interface element whose content is based on the document: use the notification to trigger a redisplay of the view.

You can use change events for the following purposes:

  • To be notified when new revisions are added to a document

  • To be notified when a document is deleted

  • To be notified when a document enters into a conflicted state

NSNotificationCenter.defaultCenter().addObserverForName(kCBLDocumentChangeNotification, object: myDocument, queue: nil) {
    (notification) -> Void in
        if let change = notification.userInfo!["change"] as? CBLDatabaseChange {
            NSLog("This is a new revision, %@", change.revisionID);
            set.setNeedsDisplay(true)
        }
}

Conflicts

So far we’ve been talking about a conflict as an error that occurs when you try to update a document that’s been updated since you read it. In this scenario, Couchbase Lite is able to stop the conflict before it happens, giving your code a chance to re-read the document and incorporate the other changes.

However, there’s no practical way to prevent a conflict when the two updates are made on different instances of the database. Neither app even knows that the other one has changed the document, until later on when replication propagates their incompatible changes to each other. A typical scenario is:

  • Molly creates DocumentA; the revision is 1-5ac

  • DocumentA is synced to Naomi’s device; the latest revision is still 1-5ac

  • Molly updates DocumentA, creating revision 2-54a

  • Naomi makes a different change to DocumentA, creating revision 2-877

  • Revision 2-877 is synced to Molly’s device, which already has 2-54a, putting the document in conflict

  • Revision 2-54a is synced to Naomi’s device, which already has 2-877, similarly putting the local document in conflict

At this point, even though DocumentA is in a conflicted state, it needs to have a current revision. That is, when your app calls getProperties, Couchbase Lite has to return something. It chooses one of the two conflicting revisions (2-877 and 2-54a) as the "winner". The choice is deterministic, which means that every device that is faced with the same conflict will pick the same winner, without having to communicate. In this case it just compares the revision IDs "2-54a" and "2-877" and picks the higher one, "2-877".

To be precise, Couchbase Lite uses the following rules to handle conflicts:

  • The winner is the undeleted leaf revision on the longest revision branch (i.e., with the largest prefix number in its revision ID.)

  • If there are no undeleted leaf revisions, the deletion (tombstone) on the longest branch wins.

  • If there’s a tie, the winner is the one whose revision ID sorts higher in a simple ASCII comparison.

Couchbase Lite does not automatically merge the contents of conflicts. Automated merging would run the risk of giving wrong or undesired results in many cases; only you know your document schemas well enough to decide how conflicts should be merged.

In some cases this simple "one revision wins" rule is good enough. For example, in a grocery list if two people rename the same item, one of them will just see that their change got overwritten, and may do it over again. But usually the details of the document content are more important, so the application will want to detect and resolve conflicts.

Resolving conflicts can also save the space in the database. Conflicting revisions stay in the database indefinitely until resolved, even surviving compactions. Therefore, it makes sense to deal with the conflict by at least deleting the non-winning revision.

Another reason to resolve conflicts is to implement business rules. For example, if two sales associates update the same customer record and it ends up in conflict, you might want the sales manager to resolve the conflict and "hand merge" the two conflicting records so that no information is lost.

There are two alternative ways to resolve a conflict:

  • Pick a winner. Just decide which of the two changes should win, and delete the other one. The deleted revision will no longer be eligible as a conflict winner, so there won’t be any more conflict.

  • Merge. Consider the contents of both conflicting revisions and construct a new revision that incorporates both. The details are, of course, application-dependent, and might even require user interaction. Then resolve the conflict by saving the merged revision, then deleting the old losing conflict revision.

The following example shows how to resolve a conflict:

let doc = database.documentWithID(myDocID)
var error: NSError?
if let conflicts = doc.getConflictingRevisions(&error) as? [CBLSavedRevision]{
    if conflicts.count > 1 {
        // There is more than one leaf revision, thus a conflict!
        database.inTransaction({ () -> Bool in
            // Come up with a merged/resolved document in some way that's
            // appropriate for the app. You could even just pick the body of
            // one of the revisions.
            var mergedProps = self.mergeRevisions(conflicts)
            // Delete the conflicting revisions to get rid of the conflict:
            var current = doc.currentRevision
            for rev in conflicts {
                var newRev = rev.createRevision()
                if rev == current {
                    // add the merged revision
                    newRev.properties = NSMutableDictionary(dictionary: mergedProps)
                } else {
                    // mark other conflicts as deleted
                    newRev.isDeletion = true
                }
                // saveAllowingConflict allows 'rev' to be updated even if it
                // is not the document's current revision.
                var error: NSError?
                if newRev.saveAllowingConflict(&error) == nil {
                    return false
                }
            }
            return true
        })
    }
}

Document Conflict FAQ

What if both devices make the same change to the document? Is that a conflict?

No. The revision ID is derived from a digest of the document body. So if two databases save identical changes, they end up with identical revision IDs, and Couchbase Lite (and the Sync Gateway) treat these as the same revision.

I deleted a document, but the it’s still in the database, only now its properties are different. What happened?

Sounds like the document was in conflict and you didn’t realize it. You deleted the winning revision, but that made the other (losing) revision become the current one. If you delete the document again, it’ll actually go away.

How can I get the properties of the common ancestor revision, to do a three-way merge?

You can’t always. Couchbase Lite isn’t a version-control system and doesn’t preserve old revision bodies indefinitely. But if the ancestor revision used to exist in your local database, and you haven’t yet compacted the database, you can still get its properties. Get the parentRevision property of the current revision to get the ancestor, then see if its properties are still non-null.

How can I tell if a document has a conflict?

Call its getConflictingRevisions method and see if more than one revision is returned.

How can I tell if there are any conflicts in the database?

Use an all-documents query with the onlyConflicts mode.

Purging documents

Purging a document is different from deleting it; it’s more like forgetting it. The purge method removes all trace of a document (and all its revisions and their attachments) from the local database. It has no effect on replication or on remote databases, though.

Purging is mostly a way to save disk space by forgetting about replicated documents that you don’t need anymore. It has some slightly weird interactions with replication, though. For example, if you purge a document, and then later the document is updated on the remote server, the next replication will pull the document into your database again.

Special Properties

The body of a document contains a few special properties that store metadata about the document. For the most part you can ignore these since the API provides accessor methods for the same information, but it can still be helpful to know what they are if you encounter them.

  • _id: The document ID.

  • _rev: The revision ID.

  • _attachments: Metadata about the document’s attachments.

  • _deleted: Only appears in a deletion (tombstone) revision, where it has the value true.

A leading underscore always denotes a reserved property—​don’t use an underscore prefix for any of your own properties, and don’t change the value of any reserved property.

Revision

Couchbase Lite uses revisions to resolve conflicts detected during replication. One significant difference from other databases is document versioning. Couchbase Lite uses a technique called Multiversion Concurrency Control (MVCC) to manage conflicts between multiple writers. This is the same technique used by version-control systems like Git or Subversion, and by WebDAV. Document versioning is similar to the check-and-set mechanism (CAS) of Couchbase Server, except that in Couchbase Lite versioning is required rather than optional and the token is a UUID rather than an integer.

Every document has a special field called _rev that contains the revision ID. The revision ID is assigned automatically each time the document is saved. Every time a document is updated, it gets a different and unique revision ID.

When you save an update to an existing document, you must include its current revision ID. If the revision ID you provide isn’t the current one, the update is rejected. When this happens, it means some other endpoint snuck in and updated the document before you. You need to fetch the new version, reconcile any changes, incorporate the newer revision ID, and try again.

Keep in mind that Couchbase Lite is not a version control system and you must not use the versioning feature in your application. They’re there only to help with concurrency and resolving conflicts during replication.

Resolving Conflicts

Revisions form a tree data structure since they can have multiple branches. In the case where there are multiple branches, one or more conflicts exist and should be resolved per the application requirements. Refer to the Resolve Conflicts section of the TodoApp tutorial to learn how to resolve conflicts in your application.

Tombstones

The reason that tombstone revisions exist is so that deletes can be sync’d to other databases. If revisions were simply deleted with a naive approach, then there would be no easy way to sync up with other databases that contained the revision.

There is a special field in a revision’s JSON called _deleted which determines whether the revision is a tombstone revision or not. A consequence of this fact is that tombstone revisions can hold arbitrary amounts of metadata, which can be useful for an application. If the full metadata of the document is preserved in the tombstone revision, then a document could easily be restored to it’s last known good state after it’s been deleted at some point.

For examples of deleting revisions via adding a tombstone revision, refer to the guide on Documents.

Saved vs Unsaved Revision

Here are the main differences between Saved and Unsaved Revision objects:

  • Unsaved revisions have not yet been persisted to the database.

  • Saved revisions have already been persisted to the database.

  • Unsaved revisions are useful for adding attachments.

Unsaved Revisions are mainly useful for manipulating attachments, since they provide the only means to do so via the API. See Attachments for examples of adding/removing attachments.

Pruning

Pruning is the process that deletes the metadata and/or JSON bodies associated with old non-leaf revisions. Leaf revisions are not impacted. The process runs automatically every time a revision is added. The maxRevTreeDepth value defaults to 20, which means that the metadata and JSON bodies of the last 20 revisions are retained in Couchbase Lite as shown on the animation below.

If there are conflicting revisions, the document may end up with disconnected branches after the pruning process. In the animation below, the document has a conflicting branch (revisions 3 - 7). When the current revision (or longest branch) reaches the 23rd update, the conflicting branch is cut off. The revision tree is not in a corrupted state and the logic that chooses the winning revision still applies. But it may make it impossible to do certain merges to resolve conflicts and occupy disk space that could have been free-ed if the conflict was resolved early on.

Compaction

Compaction is defined as the process of purging the JSON bodies of non-leaf revisions. As shown on the diagram below, only properties with a leading underscore (_ is the character to denote properties reserved for Couchbase) are kept to construct the revision tree.

Compaction can only be invoked manually via the Database.compact() method. The compaction process does not remove JSON bodies of leaf nodes. Hence, it is important to resolve conflicts in your application in order to re-claim disk space when the compaction process is executed.

Attachment

Attachments store data associated with a document, but are not part of the document’s JSON object. Their primary purpose is to make it efficient to store large binary data in a document. Binary data stored in JSON has to be base64-encoded into a string, which inflates its size by 33%. Also, binary data blobs are often large (think of camera images or audio files), and big JSON documents are slow to parse.

Attachments are uninterpreted data (blobs) stored separately from the JSON body. A document can have any number of attachments, each with a different name. Each attachment is also tagged with a MIME type, which isn’t used by Couchbase Lite but can help your application interpret its contents. On Couchbase Lite, attachments can be arbitrarily large, and are only read on demand, not when you load a Document object. On Sync Gateway, the maximum content size is 20 MB per attachment. If a document’s attachment is over 20 MB, the document will be replicated but not the attachment.

Attachments also make replication more efficient. When a document that contains pre-existing attachments is synced, only attachments that have changed since the last sync are transferred over the network. In particular, changes to document JSON values will not cause Couchbase Lite to re-send attachment data when the attachment has not changed.

In the native API, attachments are represented by the Attachment class. Attachments are available from a Revision object. From a Document, you get to the attachments via its currentRevision.

Reading attachments

The Revision class has a number of methods for accessing attachments:

  • attachmentNames returns the names of all the attachments.

  • attachmentNamed returns an Attachment object given its name.

  • attachments returns all the attachments as Attachment objects.

Once you have an Attachment object, you can access its name, MIME type and content length. The accessors for the content vary by platform: on iOS it’s available as an NSData object or as an NSURL pointing to a read-only file; in Java you read the data from an InputStream.

// Load an JPEG attachment from a document into a UIImage:
let doc = db.documentWithID("Robin")
let rev = doc.currentRevision
let att = rev.attachmentNamed("photo.jpg")
var photo: UIImage?
if att != nil {
    photo = UIImage(att.content)
}

Writing (and deleting) attachments

To create an attachment, first create a mutable UnsavedRevision object by calling createRevision on the document’s currentRevision. Then call setAttachment on the new revision to add an attachment. (You can of course also change the JSON by modifying the revision’s properties.) Finally you call save to save the new revision.

Updating an attachment’s content (or type) works exactly the same way: the setAttachment method will replace any existing attachment with the same name.

// Add or update an image to a document as a JPEG attachment:
let doc = db.documentWithID("Robin")
let newRev = doc.currentRevision.createRevision()
let imageData = UIImageJPEGRepresentation(photo, 0.75)
newRev.setAttachmentNamed("photo.jpg", withContentType: "image/jpeg", content: imageData)
var error: NSError?
assert(newRev.save(&error) != nil)

To delete an attachment, just call removeAttachment instead of setAttachment.

// Remove an attachment from a document:
let doc = db.documentWithID("Robin")
let newRev = doc.currentRevision.createRevision()
newRev.removeAttachmentNamed("phto.jpg")
var error: NSError?
assert(newRev.save(&error) != nil)

Attachment storage

In general, you don’t need to think about where and how Couchbase Lite is storing data. But since attachments can occupy a lot of space, it can be helpful to know where that space is and how it’s managed.

Attachments aren’t stored in the database file itself. Instead they are individual files, contained in a directory right next to the database file. Each attachment file has a cryptic name that is actually a SHA-1 digest of its contents.

As a consequence of the naming scheme, attachments are de-duplicated: if multiple attachments in the same database have exactly the same contents, the data is only stored once in the filesystem.

Updating a document’s attachment does not immediately remove the old version of the attachment. And deleting a document does not immediately delete its attachments. An attachment file has to remain on disk as long as there are any document revisions that reference it, And a revision persists until the next database compaction after it’s been replaced or deleted. (Orphaned attachment files are deleted from disk as part of the compaction process.) So if you’re concerned about the space taken up by attachments, you should compact the database frequently, or at least after making changes to large attachments.

View

A View is a persistent index of documents in a database, which you then query to find data. Couchbase Lite doesn’t have a query language like SQL; instead, it uses a technique called map/reduce to generate indexes (views) according to arbitrary app-defined criteria. Queries can then look up a range of rows from a view, and either use the rows' keys and values directly or get the documents they came from.

The main component of a view (other than its name) is its map function. This function is written in the same language as your app—​most likely Objective-C or Java—​so it’s very flexible. It takes a document’s JSON as input, and emits (outputs) any number of key/value pairs to be indexed. The view generates a complete index by calling the map function on every document in the database, and adding each emitted key/value pair to the index, sorted by key. For example, a map function might grind through an address-book database and produce a set of mappings from names to phone numbers. The resulting index is persistent, and updated incrementally as documents change. (It’s very much like the type of index a SQL database creates internally to optimize queries.)

A view may also have a reduce function. If present, it can be used during queries to combine multiple rows into one. It can be used to compute aggregate values like totals or averages, or to group rows by common criteria (like collecting all the artists in a record collection.) We’ll explain reduce functions later on.

A view is not a query, it’s an index. Views are persistent, and need to be updated (incrementally) whenever documents change, so having large numbers of them can be expensive. Instead, it’s better to have a smaller number of views that can be queried in interesting ways.

Creating and initializing views

View objects belong to a Database. You create or find a view by calling the database’s viewNamed method, which will create and return a new View if none exists by that name.

Even though a view is persistent, its map and reduce functions aren’t: they’re just function pointers (or blocks, or inner classes) and have to be registered at runtime, before the view is queried. It’s good practice to set up views when your app starts up, right after opening the database:

// Create a view and register its map function:
let phoneView = db.viewNamed("phones")
phoneView.setMapBlock({ (doc, emit) in
    if let phones = doc["phones"] as? [String] {
        for phone in phones {
            emit(phone, doc["name"])
        }
    }
}, version: "2")

The version parameter to setMapBlock takes a bit of explanation. During development, and as you update the app, you may change the behavior of a map function. This invalidates any existing index generated by that function, so the next time the app runs, the view should rebuild the index from scratch using the new function. Unfortunately the view indexer can’t tell that the map function has changed because it can’t see its source code! Instead, you have to provide a version string that the indexer can compare, and you must change that string whenever you change the function. The easiest thing to remember is just to set the version to "1" initially, and then increment it every time you edit any source code in the map function (or any function of yours that it calls).

Querying views

You query a view by using a Query object that you create from a View by calling createQuery. This is a big topic, and is covered in a separate article on the Query class.

Map functions

Understanding map functions

As discussed in the introduction, a map function’s job is to look at a document’s JSON contents and from them produce (emit) zero or more key/value pairs to be indexed. If you know SQL, you can think of it as corresponding to the expressions that immediately follow the SELECT and WHERE keywords, only more powerful because you have the full power of a programming language available.

For discussion purposes, here’s a simple map function in JavaScript:

function(doc) {
    if (doc["type"] == "person")
        emit(doc["name"], doc["phone"]);
}

This function works with a database that contains, among other things, documents representing people, which are tagged with a type property whose value is “person”. (This use of a type property is a common idiom.) Every person document contains name and phone properties. The map function simply checks whether the document represents a person, and if it does, it calls emit to add the name and phone number to the index.

The resulting index maps names to phone numbers. You can query it to look up someone by name and find their phone number. You can also query it to get ranges of names, in alphabetical order, which is very useful for driving GUI list views.

Rules for the map function

The map function is called by the indexer to help generate an index, and it has to meet certain requirements, otherwise the index won’t be consistent. It’s important to understand some rules so you can create a proper map function, otherwise your queries can misbehave in strange ways.

  • It must be a "https://en.wikipedia.org/wiki/Pure_function[pure]" function: That means any time it’s called with the same input, it must produce exactly the same output. In other words, it can’t use any external state, just its input JSON.

  • It can’t have side effects: It shouldn’t change any external state, because it’s unpredictable when it’s called or how often it’s called or in what order documents are passed to it.

  • It must be thread-safe: It may be called on a background thread belonging to the indexer, or even in parallel on several threads at once.

In particular, avoid these common mistakes:

  • Don’t do anything that depends on the current date and time — that breaks the first rule, since your function’s output can change depending on the date/time it’s called. Common mistakes include emitting the current time as a timestamp, emitting a person’s age, or emitting only documents that have been modified in the past week.

  • Don’t try to "parameterize" the map function by referring to an external variable whose value you change when querying. It won’t work. People sometimes try this because they want to find various subsets of the data, like all the items of a particular color. Instead, emit all the values of that property, and use a key range in the query to pick out the rows with the specific value you want.

  • Don’t make any assumptions about when the map function is called. That’s an implementation detail of the indexer. (For example, it’s not called every time a document changes.)

  • Avoid having the map function call out into complex external code. That code might change later on to be stateful or have side effects, breaking your map function.

Keys and values

Both the key and value passed to emit can be any JSON-compatible objects: not just strings, but also numbers, booleans, arrays, dictionaries/maps, and the special JSON null object (which is distinct from a null/nil pointer). In addition, the value emitted, but not the key, can be a null/nil pointer. (It’s pretty common to not need a value in a view, in which case it’s more efficient to not emit one.)

Keys are commonly strings, but it turns out that arrays are a very useful type of key as well. This is because of the way arrays are sorted: given two array keys, the first items are compared first, then if those match the second items are compared, and so on. That means that you can use array keys to establish multiple levels of sorting. If the map function emits keys of the form [lastname, firstname], then the index will be sorted by last name, and entries with the same last name will be sorted by first name, just as if you’d used ORDER BY lastname, firstname in SQL.

Here are the exact rules for sorting (collation) of keys. The most significant factor is the key’s object type; keys of one type always sort before or after keys of a different type. This list gives the types in order, and states how objects of that type are compared:

  • null

  • false, true (in that order)

  • Numbers, in numeric order of course

  • Strings, case-insensitive. The exact ordering is specified by the Unicode Collation Algorithm. This is not the same as ASCII ordering, so the results might surprise you — for example, all symbols, including "~", sort before alphanumeric characters.

  • Arrays, compared item-by-item as described above.

  • Maps/dictionaries, also compared item-by-item. Unfortunately the order of items is ambiguous (since JSON doesn’t specify any ordering of keys, and most implementations use hash tables which randomize the order) so using these as keys isn’t recommended.

The source document, and redirection

In addition to its key and value, every index row also remembers the ID of the document that emitted it. This can be accessed at query time via the QueryRow.documentID property, or more commonly via the shortcut QueryRow.document which uses the ID to load the Document object.

It can sometimes be useful to redirect this reference, i.e., to make the index row point to a different document instead. You do this by emitting a value that’s a dictionary with a key _id whose value is the document ID you want the row to reference. The QueryRow.documentID and accessors will then use this document ID instead.

// This example indexes documents that record Facebook-style "likes".
// When querying, the document we really want to look at is the post being
// liked, so we redirect the emitted row at that document.
view.setMapBlock({ (doc, emit) -> Void in
    if doc["type"] as? String == "like" {
        let associatedID = doc["likePostID"] as String
        let key = [doc["creator"]!, doc["date"]!]
        let value = ["_id": associatedID]
        emit(key, value)
    }
}, version: "1")

Even if you’ve used the redirect technique, at query time you can still recover the ID of the actual document that emitted the row, by using the QueryRow.sourceDocumentID property.

Reduce functions

Understanding reduce functions

Reduce functions are the other half of the map/reduce technique. They’re optional, and less commonly used. A reduce function post-processes the indexed key/value pairs generated by the map function, by aggregating the values together. Very commonly it counts them, or (if the values are numeric) totals or averages them. The reduce function boils down data the way a chef reduces a sauce. Or if you’re a SQL user, reduce functions are like SQL aggregation operators like COUNT or AVERAGE (only you get to define your own).

In general, most views don’t need reduce functions, so don’t feel like you’re missing something if you haven’t written one. But if you find yourself writing a query and counting the returned rows or adding up their values, you could do that more efficiently with a reduce function.

A reduce function takes an ordered list of key/value pairs, aggregates them together into a single object, and returns that object. Here’s an example, building on the phone-numbers example up above:

let phoneView = db.viewNamed("phones")
phoneView.setMapBlock({ (doc, emit) -> Void in
    if let phones = doc["phones"] as? [String] {
        for phone in phones {
            emit(phone, doc["name"])
        }
    }
}, reduceBlock: { (keys, values, rereduce) -> AnyObject! in
    return values.count
}, version: "2")

For efficiency, the key/value pairs are passed in as two parallel arrays. This reduce block just counts the number of values and returns that number as an object. We could query this view, with reduce enabled, and get the total number of phone numbers in the database. Or by specifying a key range we could find the number of phone numbers in that range, for example the number in a single area code.

Here’s just the body of a reduce function that totals up numbers. (This function would belong in a different view, whose map function emitted numeric values.)

var total: Double = 0.0
let numberValues = values as [Double];
for value in numberValues {
    total += value
}
return total

This totaling is common enough that CBLView provide a utility to do it for you, the totalValues method.

Rereducing

The previous section ignored the boolean rereduce parameter that’s passed to the reduce function. What’s it for? Unfortunately, from your perspective as a reduce-function-writer it’s just there to make your job a bit harder. The reason it exists is because it’s part of a major optimization that makes reducing more efficient for the query engine.

Think of a view with a hundred million rows in its index. To run a reduced query against the whole index (with no startKey or endKey) the database will have to read all hundred million keys and values into memory at once, so it can pass them all to your reduce function. That’s a lot of overhead, and on a mobile device it’s likely to crash your app.

Instead, the database will read the rows in chunks. It’ll read some number of rows into memory, send them to your reduce function, release them from memory, then go on to the next rows. This scales very well, but now there’s the problem of what to do with the multiple reduced values returned by your function. Reducing is supposed to produce one end result, not several! The answer is to reduce the list of reduced values — to re-reduce.

The rereduce parameter is there to tell your reduce function that it’s being called in this special re-reduce mode. When re-reducing there are no keys, and the values are the ones already returned by previous runs of the same reduce function. The function’s job is, once again, to combine the values into a single value and return it.

Sometimes you can handle re-reduce mode exactly like reduce mode. The second reduce block shown above (the one that totals up the values) can do this. Since its input values are numbers, and its output is a number, the re-reduce is done the same way as the reduce, and it can just ignore the rereduce flag.

But sometimes re-reduce has to work differently, because the output of the reduce stage doesn’t look like the indexed values. The first reduce example — the one that just counts the rows — is an example. To re-reduce a list of row counts, you can’t just count them, you have to add them. Let’s revisit that example and add proper support for re-reducing:

// Create a view and register its map and reduce functions:
let phoneView = db.viewNamed("phones")
phoneView.setMapBlock({ (doc, emit) in
    if let phones = doc["phones"] as? [String] {
        for phone in phones {
            emit(phone, doc["name"])
        }
    }
}, reduceBlock: { (keys, values, rereduce) in
    if rereduce {
        return CBLView.totalValues(values) // re-reduce mode adds up counts
    } else {
        return values.count
    }
}, version: "2")

When the rereduce flag is off, this just counts the raw values as before. But when the flag is on, it knows it’s been given an array of row counts, so it invokes the totalValues method to add them up.

Now that you know how re-reduce works, we should let you know that Couchbase Lite 1.0 doesn’t actually use re-reduce — your reduce function will always be given index rows, never already-reduced values. The rereduce parameter is in the API for future expansion, because in the future Couchbase Lite will use it. For now, it’s up to you whether you want to ignore re-reduce (and maybe find that your reduce function breaks in the future) or code defensively and implement it now even though it isn’t used yet.

Rules for the reduce function

The reduce function has the same restrictions as the map function (see above): It must be a "pure" function that always produce the same output given the same input. It must not have side effects. And it must be thread-safe. In addition:

  • Its output should be no larger than its input. Usually this comes naturally. But it is legal to return an array or dictionary, and sometimes people have tried to make reduce functions that transform the input values without actually making them any smaller. The problem with this is that it scales badly, and as the size of the index grows, the indexer will eventually run out of memory and fail.

Development considerations

Map function design

When to emit a whole document as the value? In some places you’ll see code that does something like emit(key, doc), i.e., emitting the document’s entire body as the value. (Some people seem to do this by reflex whenever they don’t have a specific value in mind.) It’s not necessarily bad, but most of the time you shouldn’t do it. The benefit is that, by having the document’s properties right at hand when you process a query row, it can make querying a little bit faster (saving a trip to the database to load the document). But the downside is that it makes the view index a lot larger, which can make querying slower. So whether it’s a net gain or loss depends on the specific use case. We recommend that you just set the value to null if you don’t need to emit any specific value.

Is it OK is the same key is emitted more than once? The index allows duplicate keys, whether emitted by the same document or different documents. A query will return all of those key/value pairs if they match. They’ll be sorted by the ID of the document that was responsible for emitting them; if a doc emits the same key multiple times, the order is undefined.

When is the map function called? View indexes are updated on demand when queried. So after a document changes, the next query made to a view will cause that view’s map function to be called on the doc’s new contents, updating the view index. (But remember that you shouldn’t write any code that makes assumptions about when map functions are called.)

If a document has conflicts, which conflicting revision gets indexed? The document’s currentRevision, sometimes called the "winning" revision, is the one that you see in the API if you don’t request a revision by ID.

Performance

How to improve your view indexing: The main thing you have control over is the performance of your map function, both how long it takes to run and how many objects it allocates. Try profiling your app while the view is indexing and see if a lot of time is spent in the map function; if so, optimize it. See if you can short-circuit the map function and give up early if the document isn’t a type that will produce any rows. Also see if you could emit less data. (If you’re emitting the entire document as a value, don’t.)

Query

A query is the action of looking up results from a view’s index. In Couchbase Lite, queries are objects of the Query class. To perform a query you create one of these, customize its properties (such as the key range or the maximum number of rows) and then run it. The result is a QueryEnumerator, which provides a list of QueryRow objects, each one describing one row from the view’s index.

There’s also a special type of query called an all-docs query. This type of query isn’t associated with any view; or rather, you can think of it as querying an imaginary view that contains one row for every document in the database. You use an all-docs query to find all the documents in the database, or the documents with keys in a specific range, or even the documents with a specific set of keys. It can also be used to find documents with conflicts.

Couchbase Lite also provides live queries. Once created, a live query remains active and monitors changes to the view’s index, notifying observers whenever the query results change. Live queries are very useful for driving UI components like table views.

Creating and configuring queries

Query objects are created by a View's `createQuery method, and by a Database's `createAllDocumentsQuery method. In its default state a Query object will return every row of the index, in increasing order by key. But there are several properties you can configure to change this, before you run the query. Here are the most basic and common ones:

  • startKey: the key to start at. The default value, null, means to start from the beginning.

  • endKey: the last key to return. The default value, null, means to continue to the end.

  • descending: If set to true, the keys will be returned in reverse order. (This also reverses the meanings of the startKey and endKey properties, since the query will now start at the highest keys and end at lower ones!)

  • limit: If nonzero, this is the maximum number of rows that will be returned.

  • skip: If nonzero, this many rows will be skipped (starting from the startKey if any).

Some more advanced properties that aren’t used as often:

  • keys: If provided, the query will fetch only the rows with the given keys (and startKey and endKey will be ignored).

  • startKeyDocID: If multiple index rows match the startKey, this property specifies that the result should start from the one(s) emitted by the document with this ID, if any. (Useful if the view contains multiple identical keys, making .startKey ambiguous.)

  • endKeyDocID: If multiple index rows match the endKey, this property specifies that the result should end with from the one(s) emitted by the document with this ID, if any. (Useful if the view contains multiple identical keys, making .startKey ambiguous.)

  • indexUpdateMode: Changes the behavior of index updating. By default the index will be updated if necessary before the query runs. You can choose to skip this (and get possibly-stale results), with the option of also starting an asynchronous background update of the index.

  • prefixMatchLevel: If nonzero, enables prefix matching of string or array keys.

    • A value of 1 treats the endKey itself as a prefix: if it’s a string, keys in the index that come after the endKey, but begin with the same prefix, will be matched. (For example, if the endKey is "foo" then the key "foolish" in the index will be matched, but not "fong".) Or if the endKey is an array, any array beginning with those elements will be matched. (For example, if the endKey is [1], then [1, "x"] will match, but not [2].) If the key is any other type, there is no effect.

    • A value of 2 assumes the endKey is an array and treats its final item as a prefix, using the rules above. (For example, an endKey of [1, "x"] will match [1, "xtc"] but not [1, "y"].)

    • A value of 3 assumes the key is an array of arrays, etc.

      Note that if the .descending property is also set, the search order is reversed and the above discussion applies to the startKey` not the endKey.

There are other advanced properties that only apply to reducing and grouping:

  • mapOnly: If set to true, prevents the reduce function from being run, so you get all of the index rows instead of an aggregate. Has no effect if the view has no reduce function.

  • groupLevel: If greater than zero, enables grouping of rows. The value specifies the number of items in the value array that will be grouped.

// Set up a query for a view that indexes blog posts, to get the latest:
let query = db.viewNamed("postsByDate").createQuery()
query.descending = true
query.limit = 20

All-documents queries

An all-docs query isn’t associated with a view; or rather, you can think of it as querying an imaginary view that contains one row for every document in the database, whose key is the document ID. It supports all the standard view options, so you can query ranges of document IDs, reverse the order, and even query a specific set of documents using the keys property.

All-docs queries also have a special property called allDocsMode that can customize their behavior. Its values are:

  • allDocs: The default mode. Returns all non-deleted documents.

  • includeDeleted: In this mode, deleted documents are included as well.

  • showConflicts: In this mode, each QueryRow's `conflictingRevisions property can be used to find whether it’s in conflict and what the IDs of the conflicting revisions are.

  • onlyConflicts: Like showConflicts, but only conflicted documents are returned.

(These are not flags. You can only choose one.)

// Let's find the documents that have conflicts so we can resolve them:
let query = db.createAllDocumentsQuery()
query.allDocsMode = CBLAllDocsMode.OnlyConflicts
var error: NSError?
let result = query.run(&error)
while let row = result?.nextRow() {
    NSLog("!!! Conflict in document %@", row.documentID);
    self.beginConflictResolution(row.document)
}

Running queries

After a Query object is set up just right, you call its run method to get the results. These are returned as a QueryEnumerator object, which mainly serves as an enumerable collection of QueryRow objects.

Each QueryRow has two main properties, its key and its value. These are what were emitted to the index. (Or in the case of an all-docs query, the key is the same as the document ID.) It also has a documentID property that identifies the document that the key and value were emitted from, although usually you’d access the document property instead, which gives you the Document object directly.

// Let's query a view that maps product names to prices,
// starting with the "M"s and showing 100 widgets:
let query = db.viewNamed("widgetsByName").createQuery()
query.startKey = "m"
query.limit = 100
var error: NSError?
let result = query.run(&error)
while let row = result?.nextRow() {
    NSLog("Widget named %@ costs $%.2f", row.key as String, row.value as Double);
}

Re-running queries, and LiveQuery

It’s OK to run the same Query again. You can even change its settings before the next run. But if you find yourself wanting to re-run a query over and over to check for updates, there are some optimizations to consider.

First, there’s a quick check to see whether the previous query results are still up to date. If you keep the QueryEnumerator object and check its stale property, a false value means that the view index hasn’t changed and re-running the query won’t give you a different result set.

Second, even if the enumerator says it’s stale and you re-run the query, the new results might not be any different. The stale method is conservative and might report false positives, and even if the index did change, your query might not include any of the changed rows. You can quickly check if the new QueryEnumerator you got is equivalent to the old one by comparing the objects for equality (e.g., using equals in Java, or -isEqual: in Objective-C).

// Check whether the query result set has changed:
if (queryResult == nil || queryResult.stale) {
    let newResult = query.run(&error)
    if (queryResult != newResult) {
        queryResult = newResult
        self.updateMyUserInterface()
    }
}

There’s a class that actually does this work for you, called LiveQuery. A live query stays active and monitors the database and view index for changes. When there’s a change it re-runs itself automatically, and if the query results changed it notifies any observers. LiveQuery is a great way to build reactive user interfaces, especially table/list views, that keep themselves up to date. For example, as the replicator runs and pulls new data from the server, a LiveQuery-driven UI will automatically update to show the data without the user having to manually refresh. This helps your app feel quick and responsive.

func initializeQuery() {
    let query = db.viewNamed("widgets").createQuery()
    query.limit = 100
    liveQuery = query.asLiveQuery()
    liveQuery.addObserver(self, forKeyPath: "rows", options: nil, context: nil)
    liveQuery.start()
}
override func observeValueForKeyPath(keyPath: String, ofObject object: AnyObject,
    change: [NSObject : AnyObject], context: UnsafeMutablePointer<Void>) {
    if object as? NSObject == liveQuery {
        displayRows(liveQuery.rows)
    }
}

Querying key ranges

There are some subtleties to working with key ranges (startKey and endKey). The first is that if you reverse the order of keys, by setting the reverse property, then the startKey needs to be greater than the endKey. That’s the reason they’re named start and end, rather than min and max. In the following example, note that the key range starts at 100 and ends at 90; if we’d done it the other way around, we’d have gotten an empty result set.

// Set up a query for the highest-rated movies:
let query = db.viewNamed("postsByDate").createQuery()
query.descending = true
query.startKey = 100 // Note the start key is higher than the end key
query.endKey = 90

Second is the handling of compound (array) keys. When a view’s keys are arrays, it’s very common to want to query all the rows that have a specific value (or value range) for the first element. The start key is just a one-element array with that value in it, but it’s not obvious what the end key should be. What works is an array that’s like the starting key but with a second object appended that’s greater than any possible value. For example, if the start key is (in JSON) ["red"] then the end key could be ["red", "ZZZZ"] …​ because none of the possible second items could be greater than "ZZZZ", right? Unfortunately this has obvious problems. The correct stop value to use turns out to be an empty object/dictionary, {}, making the end key ["red", {}]. This works because the sort order in views puts dictionaries last.

// Assume the view's keys are like [color, model]. We want all the red ones.
let query = db.viewNamed("carsByColorAndModel").createQuery()
query.startKey = ["red"]
query.endKey = ["red",[:]]

Reducing

If the view has a reduce function, it will be run by default when you query the view. This means that all rows of the output will be aggregated into a single row with no key, whose value is the output of the reduce function. (See the View documentation for a full description of what reduce functions do.)

(It’s important to realize that the reduce function runs on the rows that would be output, not all the rows in the view. So if you set the startKey and/or endKey, the reduce function runs only on the rows in that key range.)

If you don’t want the reduce function to be used, set the query’s mapOnly property to true. This gives you the flexibility to use a single view for both detailed results and statistics. For example, adding a typical row-count reduce function to a view lets you get the full results (with mapOnly=true) or just the number of rows (with mapOnly=false).

// This view's keys are order dates, and values are prices.
// The reduce function computes an average of the input values.
let query = ordersByDateView.createQuery()
query.startKey = "2014-01-01"
query.endKey = "2014-02-01"
query.inclusiveEnd = false
// First run without reduce to get the individual orders for January '14:
query.mapOnly = true
var error: NSError?
var result = query.run(&error)
while let row = result?.nextRow() {
    NSLog("On %@: order for $%.2f", row.key as String, row.value as Double);
}
// Now run with reduce to get the average order price for January '14:
query.mapOnly = false
result = query.run(&error)
if let aggregate = result?.nextRow() {
    NSLog("Average order was $%.2f", aggregate.value as Double)
}

Grouping by key

The groupLevel property of a query allows you to collapse together (aggregate) rows with the same keys or key prefixes. And you can compute aggregated statistics of the grouped-together rows by using a reduce function. One very powerful use of grouping is to take a view whose keys are arrays representing a hierarchy — like [genre, artist, album, track] for a music library — and query a single level of the hierarchy for use in a navigation UI.

In general, groupLevel requires that the keys be arrays; rows with other types of keys will be ignored. When the groupLevel is n, the query combines rows that have equal values in the first n items of the key into a single row whose key is the n-item common prefix.

groupLevel=1 is slightly different in that it supports non-array keys: it compares them for equality. In other words, if a view’s keys are strings or numbers, a query with groupLevel=1 will return a row for each unique key in the index.

We’ve talked about the keys of grouped query rows, but what are the values? The value property of each row will be the result of running the view’s reduce function over all the rows that were aggregated; or if the view has no reduce function, there’s no value. (See the View documentation for information on reduce functions.)

Here’s an interesting example. We have a database of the user’s music library, and a view containing a row for every audio track, with key of the form [genre, artist, album, trackname] and value being the track’s duration in seconds. The view has a reduce function that simply totals the input values. The user’s drilled down into the genre "Mope-Rock", then artist "Radiohead", and now we want to display the albums by this artist, showing each album’s running time.

var albumTitles: [String] = []
var albumTimes: [Int] = []
var error: NSError?
let result = query.run(&error)
while let row = result?.nextRow() {
    albumTitles.append(row.keyAtIndex(2) as String)
    albumTimes.append(row.value as Int)
}

Replication

A Replication object represents a replication (or "sync") task that transfers changes between a local database and a remote one. To replicate, you first get a new Replication object from a Database, then configure its settings, then tell it to start. The actual replication runs asynchronously on a background thread; you can monitor its progress by observing notifications posted by the Replication object when its state changes, as well as notifications posted by the database when documents are changed by the replicator.

A typical application will create a pair of replications (push and pull) at launch time, both pointing to the URL of a server run by the application vendor. These stay active continuously during the lifespan of the app, uploading and downloading documents as changes occur and when the network is available.

(Of course, atypical applications can use replication differently. The architecture is very flexible, supporting one-way replication, peer-to-peer replication, and replication between multiple devices and servers in arbitrary directed graphs. An app might also choose to replicate only once in a while, or only with a subset of its documents.)

The application code doesn’t have to pay attention to the details: it just knows that when it makes changes to the local database they will eventually be uploaded to the server, and when changes occur on the server they will eventually be downloaded to the local database. The app’s job is to make the UI reflect what’s in the local database, and to reflect user actions by making changes to local documents. If it does that, replication will Just Work without much extra effort.

Types of replications

  • Push vs Pull: A push replication uploads changes from the local database to the remote one; a pull downloads changes from the remote database to the local one.

  • One-shot vs Continuous: By default a replication runs long enough to transfer all the changes from the source to the target database, then quits. A continuous replication, on the other hand, will stay active indefinitely, watching for further changes to occur and transferring them.

  • Filtered: Replications can have filters that restrict what documents they’ll transfer. This can be useful to limit the amount of a large remote database that’s downloaded to a device, or to keep some local documents private. A special type of filter used with the Couchbase Sync Gateway is the set of channels that a pull replication will download from. It’s also possible to limit a replication to an explicit set of document IDs.

Creating replications

You create a Replication object by calling the Database methods createPullReplication or createPushReplication. Both of these take a single parameter, the URL of the remote database to sync with. As the names imply, each method creates a replication that transfers changes in one direction only; if you want bidirectional sync, as most apps do, you should create one of each.

Next you can customize the replication settings. The most common change is to set the continuous property to true. You may also need to supply authentication credentials, like a username/password or a Facebook token.

let url = NSURL(string: "https://example.com/mydatabase/")
let push = database.createPushReplication(url)
let pull = database.createPullReplication(url)
push.continuous = true
pull.continuous = true
var auth: CBLAuthenticatorProtocol?
auth = CBLAuthenticator.basicAuthenticatorWithName(username, password: password)
push.authenticator = auth
pull.authenticator = auth

You will also probably want to monitor the replication’s progress, particularly because this will tell you if errors occur, but also if you want to display a progress indicator to the user. The API for registering as an observer is platform-specific.

Once everything is set, you call start to start the replication. If the replication is continuous, it’ll keep running indefinitely. Otherwise, the replication will eventually stop when it’s transferred everything.

NSNotificationCenter.defaultCenter().addObserver(self,
    selector: "replicationChanged", name: kCBLReplicationChangeNotification, object: push)
NSNotificationCenter.defaultCenter().addObserver(self,
    selector: "replicationChanged", name: kCBLReplicationChangeNotification, object: pull)
push.start()
pull.start()
// It's important to keep a reference to a running replication,
// or it is likely to be dealloced!
self.push = push;
self.pull = pull;
// The replications are running now; the -replicationChanged: method will
// be called with notifications when their status changes.

Filtered replications

You can restrict a replication to only a subset of the available documents, by writing a filter function. There are several types of filtered replication, based on the direction and the type of server.

Filtered push replications

During a push replication, the candidate documents live in your local database, so the filter function runs locally. You define it as a native function (a block in Objective-C, an inner class method in Java), assign it a name, and register it with the Database object. You then set the filter’s name as the filter property of the Replication object.

The replicator passes your filter function a SavedRevision object. The function can examine the document’s ID and properties, and simply returns true to allow the document to be replicated, or false to prevent it from being replicated.

The filter function will be called on the replicator’s background thread, so it should be thread-safe. Ideally it shouldn’t reference any external state, but this isn’t strictly required.

The filter function can also be given parameters. The parameter values are specified in the Replication.filterParams property as a dictionary/map, and passed to the filter function. This way you can write a generalized filter that can be used with different replications, and also avoid referencing external state from within the function. For example, a function could filter documents created in any year, accepting the specific year as a parameter.

db.setFilterNamed("byOwner", asBlock: {
    (revision, params) -> Bool in
        let nameParam = params["name"] as? String
        return nameParam != nil && nameParam! == revision["owner"] as? String
})
//
// Set up a filtered push replication using the above filter block,
// that will push only docs whose "owner" property equals "Waldo":
var push = db.createPushReplication(url)
push.filter = "byOwner"
push.filterParams = ["name": "Waldo"]

Filtered pull from Sync Gateway

Channels are used to filter documents being pulled from the Sync Gateway. Every document stored in a Sync Gateway database is tagged with a set of named channels by the Gateway’s app-defined sync function. Every pull replication from the Gateway is already implicitly filtered by the set of channels that the user’s account is allowed to access; you can filter it further by creating an array of channel names and setting it as the value of the channels property of a pull Replication. Only documents tagged with those channels will be downloaded.

// Set up a channel-filtered pull replication that will pull only
// docs in the "sales" channel from the Sync Gateway:
var pull: CBLReplication = database.createPullReplication(url)
pull.channels = ["sales"]
Replication properties changed after it has already started won’t have any effect. If you wish to change replication properties such as channels, authentication, etc, you must create a new replication object using the createPushReplication or createPullReplication method.

Filtered pull from CouchDB, PouchDB or Cloudant

Since Couchbase Lite 1.2, filter functions in pull replications with non-Couchbase databases are no longer available. There is an incompatibility in the way the filter parameter is handled in the POST /{db}/_changes request (see #1139).

Filtering by document IDs

In one-shot pull replications with Sync Gateway, it’s possible to specify a list of document IDs (this feature is not available for replications in continuous mode, see #1703). The code below pulls the documents with ID "123" and "xyz" if they exist and the user has access to them.

let pull = database.createPullReplication(kSyncGatewayUrl)
pull.documentIDs = ["123", "xyz"]
pull.start()

For push replications with Sync Gateway, this functionality is available in one-shot and continuous replications.

Observing and monitoring replications

Since a replication runs asynchronously, if you want to know when it completes or when it gets an error, you’ll need to register as an observer to get notifications from it. The details of this are platform-specific.

A replication has a number of properties that you can access, especially from a notification callback, to check on its status and progress:

  • status: An enumeration that gives the current state of the replication. The values are Stopped, Offline, Idle and Active.

    • Stopped: A one-shot replication goes into this state after all documents have been transferred or a fatal error occurs. (Continuous replications never stop.)

    • Offline: The remote server is not reachable. Most often this happens because there’s no network connection, but it can also occur if the server’s inside an intranet or home network but the device isn’t. (The replication will monitor the network state and will try to connect when the server becomes reachable.)

    • Idle: Indicates that a continuous replication has "caught up" and transferred all documents, but is monitoring the source database for future changes.

    • Active: The replication is actively working, either transferring documents or determining what needs to be transferred.

  • lastError: The last error encountered by the replicator. (Not all errors are fatal, and a continuous replication will keep running even after a fatal error, by waiting and retrying later.)

  • completedChangesCount, changesCount: The number of documents that have been transferred so far, and the estimated total number to transfer in order to catch up. The ratio of these can be used to display a progress meter. Just be aware that changesCount may be zero if the number of documents to transfer isn’t known yet, and in a continuous replication both values will reset to zero when the status goes from Idle back to Active.

NSNotificationCenter.defaultCenter().addObserver(self,
    selector: "replicationChanged:",
    name: kCBLReplicationChangeNotification,
    object: push)
NSNotificationCenter.defaultCenter().addObserver(self,
    selector: "replicationChanged:",
    name: kCBLReplicationChangeNotification,
    object: pull)
func replicationChanged(n: NSNotification) {
    // The replication reporting the notification is n.object , but we
    // want to look at the aggregate of both the push and pull.

    // First check whether replication is currently active:
    let active = pull.status == CBLReplicationStatus.Active || push.status == CBLReplicationStatus.Active
    self.activityIndicator.state = active
    // Now show a progress indicator:
    self.progressBar.hidden = !active;
    if active {
        var progress = 0.0
        let total = push.changesCount + pull.changesCount
        let completed = push.completedChangesCount + pull.completedChangesCount
        if total > 0 {
            progress = Double(completed) / Double(total);
        }
        self.progressBar.progress = progress;
    }
}

Detecting unauthorized credentials

The replication listener can also be used to detect when credentials are incorrect or access to Sync Gateway requires authentication.

    ...

    NSNotificationCenter.defaultCenter().addObserver(self, selector: "changeListener:", name: kCBLReplicationChangeNotification, object: push)
    NSNotificationCenter.defaultCenter().addObserver(self, selector: "changeListener:", name: kCBLReplicationChangeNotification, object: pull)
}

func changeListener(notification: NSNotification) {
    if (push.status == CBLReplicationStatus.Active || pull.status == CBLReplicationStatus.Active) {
        print("Sync in progress")
    } else {
        let error = push.lastError ?? pull.lastError
        print("Error with code \(error?.code)")
        if error?.code == 401 {
            print("Authentication error")
        }
    }
}

Data Modeling

If you’re familiar with data modeling for relational databases, you’ll notice differences in the way it is done for Couchbase Lite.

Couchbase Lite is a document database. Unlike traditional relational databases, data is stored in documents rather than in table rows. A document is a JSON object containing a number of key-value pairs. Entities, and relationships between entities, are managed within the document itself.

The Basics

A starting point for data modeling in Couchbase Lite is to look at a denormalized entity stored in a single document. Consider modeling a contact record stored in a relational database in a CONTACTS table, of the form:

ID FIRST_NAME LAST_NAME EMAIL

100

John

Smith

john.smith@couchbase.com

The equivalent representation in JSON document form would be something like:

{
   "id": "contact100",
   "type": "contact",
   "first_name":"John",
   "last_name ":"Smith",
   "email": "john.smith@couchbase.com"
}

Functionally related properties can be grouped using an embedded document. If we wanted to store address information for our contact, it could be modeled as:

{
   "id": "contact100",
   "type": "contact",
   "first_name": "John",
   "last_name ": "Smith",
   "email": "john.smith@couchbase.com",
   "address": {
      "address_line": "123 Main Street",
      "city": "Mountain View",
      "country": "US"
   }
}

One-to-Many Relationships

Things get interesting when the contact record has more than one related record that we want to model. There are two main options for modeling one-to-many relationships in a document database — as embedded documents, and as related documents.

Using Embedded Documents

When a contact can have more than one address, the addresses would commonly be stored in a relational database using a separate ADDRESSES table:

ID CONTACT_ID ADDRESS_LINE CITY COUNTRY

200

100

123 Main Street

Mountain View

US

201

100

123 Market

San Francisco

US

In a document database, the address information could instead be stored as an array of embedded documents within the contact document:

{
   "id": "contact100",
   "type": "contact",
   "first_name": "John",
   "last_name" : "Smith",
   "email": "john.smith@couchbase.com",
   "addresses": [
    {
      "address_line": "123 Main Street",
      "city": "Mountain View",
      "country": "US"
    },
    {
      "address_line": "123 Market",
      "city": "San Francisco",
      "country": "US"
    }
   ]
}

The embedded document approach reduces the amount of work that your application needs to do in order to work with the Contact object — there is no additional query required to retrieve the embedded information.

There are scenarios where the embedded document approach isn’t ideal, including:

  • Large number of related entities. Embedding a large number of related entities results in a large document. This can result in slower document handling, as the entire document needs to be passed around when making updates.

  • Concurrency. When multiple users are working on a single document, there’s a higher risk of conflicts being introduced. Related documents can be used to isolate updates being made by different users.

The most common implementation for related documents is the belongsTo pattern. Consider the scenario where any user can assign a task to a contact, and a contact can end up with a large number of volatile task records. Here we define a new task document, which includes the contact key that the task record belongs to:

{
  "id": "task300",
  "type": "task",
  "contact_id": "contact100"
  "description": "Task details",
  "status": "complete"
}

Under this implementation, users can modify task records concurrently without introducing conflict scenarios for the related contact record. It can also support a large number of task records per contact without impacting the size of the related contact record.

Model

Most applications use the Model/View/Controller design pattern to separate user interface and user interaction from underlying data structures and logic. Of course, one of the responsibilities of the app’s object model is persistence.

Couchbase Lite on iOS provides support for creating model objects that persist to Couchbase Lite documents, and can be queried using Couchbase Lite queries. You subclass the abstract class CBLModel and add your own properties, plus a very small amount of annotation that defines how those properties map to JSON in the document.

What model objects give you

  • Native property access: Access document properties as native properties.

  • Extended type support: Transparent support for common types that don’t have a JSON representation, like NSDate and NSData. You can even represent references to other model objects.

  • Mutable state: Properties can be readwrite, so they can be changed in memory, then later saved back to the document.

  • Key-Value Observing: You can observe the value of a property and get notified when it changes. On Mac OS X, you can also use bindings to connect properties to UI controls.

  • Dynamic typing: You can use the CBLModelFactory to associate each model class with a document type. You can create a hierarchy of model classes and have the appropriate subclass instantiated at runtime according to the document’s type.

Defining model classes

To create your own model class, just make it inherit from CBLModel. You can create any number of model classes, and they can inherit from each other. Each model class will correspond to a different type of persistent entity in your application.

You define persistent properties of your model classes simply by declaring Objective-C properties in its @interface block using the @property syntax. To mark a property as persistent, in the @implementation block you must declare it as being @dynamic, as shown in the next example.

If you forget to declare a persistent property as @dynamic, the compiler will automatically synthesize a regular instance variable with getter/setter methods, so your program will compile and will appear to work except that the property won’t be persistently saved to the document. This can be hard to debug! You can have the compiler flag missing @dynamic declarations by enabling the "Implicit Synthesized Properties" warning in the Xcode target build settings, but if you do this you’ll also need to explicitly use @synthesize declarations for all synthesized properties.
@objc(Note)
class Note: CBLModel {
    @NSManaged var message: NSString
    @NSManaged var created: NSDate
    @NSManaged var checked: Bool
}

This is all the code you need to write for a minimal but fully functional model class. The name of the property is exactly the same as the name of the JSON property in the document. If you’re defining a model class for pre-existing documents, make sure you spell the property names the same way, including capitalization and underscores.

Types of properties and how they’re stored

CBLModel supports a pretty broad range of data types for properties, but not everything goes, and some types require special handling. Types that can’t be directly represented in JSON — like dates — will be converted to a string representation, but will be properly converted back to the property’s native type when the model object is next read from the database.

  • Numeric types: All numeric types will be stored in JSON as numbers.

  • Booleans: Declare boolean properties as the C99 type bool, not the legacy Objective-C type BOOL. (Why not? The latter is really just a typedef for char, so at runtime it just looks like an 8-bit integer, which means it’ll be stored in JSON as 0 or 1, not true or false.)

  • NSString: Maps to a JSON string, of course.

  • NSDate: JSON doesn’t have a date type, so the date will be stored as a string in the semi-standard ISO-8601 format, and parsed from that format when read in.

  • NSData: JSON doesn’t support binary data, so the data will be encoded as Base64 and stored as a string. (The size and CPU overhead of the conversion make this inefficient for large data. Consider using an attachment instead.)

  • Other CBLModel classes: You can create a one-to-one references to another model object by declaring a persistent property whose type is a CBLModel subclass. The value will be persisted as a JSON string containing the document ID of the model object.

  • NSArray: An NSArray is saved as a JSON array, with each element of the array converted to JSON according to the rules in this section. When reading a JSON array from a document, however, it can be ambiguous what type of object to use; there are annotations that can customize that. See below.

  • Any class implementing CBLJSONEncoding: CBLJSONEncoding is a protocol defined by Couchbase Lite. Any class of yours that implements this protocol can be used as the type of a persistent property; CBLModel will call the CBLJSONEncoding API to tell the object to convert itself to/from JSON.

If an object-valued property has a value of nil, its corresponding JSON property will be left out entirely when saving the document; it will not be written with a JSON null as a value. Similarly, any missing property in the JSON will be converted to a nil or 0 or false value.

If a JSON value read from a document has a type that’s incompatible with the corresponding model property — like a string when the property type is int — the model property will be set to the appropriate empty value (0, false, or nil). If you need stricter type matching, you should add a validation function to the Database, to ensure that documents have the correct JSON property types.

CBLJSONEncoding

A CBLModel always represents an entire document. The CBLJSONEncoding protocol, on the other hand, can be used to represent part of a document.

If a model class indicates that one of its properties is of a custom class that implements that protocol, then the protocol’s init method will be used to construct the object from the JSON object. Likewise, if a property value in memory is an instance of the protocol, the encodeAsJSON method will be used to get a JSON representation.

Let’s consider the following document as a JSON schema:

{
  "title": "New note",
  "user": {
    "name": "jack"
  }
}

The following example maps that document as two native classes: the Note class which is the model class and the User class which represents the user fragment in the JSON schema.

@objc(Note)
class Note: CBLModel {
    @NSManaged var title: String
    @NSManaged var user: User
}

@objc(User)
class User: NSObject, CBLJSONEncoding {
    var name: String = ""

    required init?(json jsonObject: Any) {
        super.init()
        guard let jsonObject = jsonObject as? [String : AnyObject] else { return }
        self.name = jsonObject["name"] as! String
    }

    func encodeAsJSON() -> Any {
        return ["name": self.name]
    }
}

Array element types

The NSArray property type often needs special handling, to ensure that the items of JSON arrays are converted to the correct type of object. By default, the items are simply parsed as JSON; this breaks round-trip fidelity if you store NSDate or NSData or CBLModel objects — they’ll all be read back in as NSStrings. And if you store objects implementing CBLJSONEncoding, they’ll be read back in as whatever JSON-compatible value the object encoded itself as.

To prevent this, you can specify that the items of the array property must be of a particular class. Each item will then be converted from JSON according to the property-type rules for that class, described in the previous section. To specify the type, implement a class method with a name of the form property name ItemClass, as in this example:

@objc(Star)
class Star: CBLModel {
    @NSManaged var observationDates: NSArray // items are NSDates
    class func observationsItemClass() -> AnyClass {
        return NSDate.self
    }
}

Raw access to document properties

You don’t have to create a native property for every document property. It’s possible to access arbitrary document properties by name, by calling -getValueOfProperty: and -setValue:ofProperty:.

// Let's say Note documents have a JSON property "type" that we haven't
// defined a property for. We can access it like this:
let noteType = note.getValueOfProperty("type") as String
note.setValue(noteType, ofProperty: "type")

Attachments

Model objects also support access to document attachments. The API is very similar to that of the UnsavedRevision class: you can access attachments using the attachmentNames property and attachmentNamed method, and modify attachments using setAttachmentNamed and removeAttachmentNamed. (Changes to attachments aren’t saved to the database until the model object is saved.)

Instantiating model objects

Remember that every model has a one-to-one association with a document in the database. CBLModel has no public initializer methods, and you should not implement any yourself in subclasses.

To create a new model object on a new document, use the following class method:

let newNote = Note(forNewDocumentInDatabase: self.database);

In a subclass, to set up a transient state of an instance, override the awakeFromInitializer instance method. This method is called when a new model is instantiating.

To instantiate the model for an existing document (or even a document that doesn’t exist yet but which you want to have a specific ID):

let doc = self.database["some-note"]
let note = Note(forDocument: doc)

The +modelForDocument: method is inherited from CBLModel; you don’t need to override it. But it always creates an instance of the class that it’s invoked on, Note in the example.

There is never more than one model object for a particular document. If you call +modelForDocument: again on the same CBLDocument, it will return the same model object.

Custom initialization

If your subclass needs to initialize state when it’s created, you should create a class method with the desired parameters and call the modelForDocumentInDatabase class method:

class Note: CBLModel {
    @NSManaged var title: String

    class func newNoteInDatabase(database: CBLDatabase, withTitle title: String) -> Note {
        let note = Note(forNewDocumentInDatabase: database)
        note.title = title
        return note
    }
}

Dynamic instantiation using the model factory

There’s one limitation of the default mechanism of instantiating model objects: you have to know what class the model object will be before you instantiate it, since you call +modelForDocument: on that specific class. This can be a problem if you have a hierarchy of model classes, and want to instantiate different subclasses for different types of documents.

For example, let’s say you have a fancy to-do list that supports not just text notes but voice notes and picture notes. You’ve created VoiceNote and PictureNote subclasses of Note for these, and the documents in the database follow the convention of using a "type" property to identify their type, with values "note", "voice_note" and "picture_note". Now, any time you want to instantiate a model object, it seems you’ll first have to look at the document’s "type" property, match the value to a Note class, and instantiate that class:

// This is the CLUMSY and INEFFICIENT way to handle dynamic typing:
let doc = self.database["some-note"]
var note: Note?
let type = doc["type"] as? String;
if type == "note" {
    note = Note(forDocument: doc)
} else if type == "voice_note" {
    note = VoiceNote(forDocument: doc)
} else if type == "picture_note" {
    note = PictureNote(forDocument: doc)
} else {
    note = nil
}

Even worse, let’s say you have a model class that has a reference to a Note, i.e., a property of type Note*. When resolving this property value, CBLModel will instantiate a Note object, even if the document’s type indicates it should be represented by a VoiceNote or PictureNote!

To solve these problems, register your model classes with the database’s ModelFactory, specifying a different "type" value for each one:

// Do this once per launch, probably right after opening the database:
let factory = self.database.modelFactory
factory.registerClass(Note.self, forDocumentType: "note")
factory.registerClass(VoiceNote.self, forDocumentType: "voice_note")
factory.registerClass(PictureNote.self, forDocumentType: "picture_note")

Once you’ve done this, you can now call +modelForDocument: directly on CBLModel, instead of on your subclass; the method will look up the document’s type in the model factory to find out what class to instantiate.

// This is the clean way to handle dynamic typing:
let doc = self.database["some-note"]
let note = CBLModel(forDocument: doc) as Note

This doesn’t look much different from the usual style; but by letting CBLModel choose the class, you’ll dynamically get an object of the correct subclass (Note, VoiceNote or PictureNote) based on the "type" property of the individual document. Also, when resolving a property value whose type is a model class, the factory will be used to ensure that the correct subclass is instantiated.

For this to work, you do have to make sure your model object sets the document’s "type" property appropriately!

Saving model objects

Model objects can have mutable state: their properties can be declared readwrite, and their attachments can be modified. Such changes are made only in memory, and don’t affect the underlying Document until the model object is saved.

// Toggle a note's checkbox property and save it:
note.checked = !note.checked
var error: NSError?
if !note.save(&error) {
    handleError(error)
}
You can efficiently save all changed models at once, by calling the database’s saveAllModels method.

If you don’t want to deal with saving manually, you can set a model object’s autosaves property. When this boolean property is set, the model will automatically call save: shortly after its state is changed. (The save occurs after the current thread returns back to the runloop, and only happens once even if multiple changes were made.)

You can increase the delay before the auto-save by overriding the autosaveDelay property, whose default value is 0, to a longer time interval.

If instead you want to undo all changes and revert the model object back to the document’s state, call revertChanges.

To delete the document, call deleteDocument:. (Afterwards, don’t use the model object anymore; with a deleted document it’s no longer in a useable state.)

Customizing saving

If you need to do something just before a model is saved, don’t override save — it isn’t called in all cases where the model gets saved. Instead, override willSave. This is guaranteed to be called right before a save. It’s passed a set of the names of all the modified properties, which could be useful. Your implementation can even change property values if it wants to, for instance to update a timestamp:

override func willSave(changedPropertyNames: NSSet!) {
    saveCount++
    lastSaveTime = NSDate()
}

You may need a specific type of customization when deleting a model’s document: storing some information in the deleted document’s "tombstone" revision, generally for the use of the server. To do this, override propertiesToSaveForDeletion and return an NSDictionary of properties. It’s best to call the base implementation and modify the dictionary it returns:

override func propertiesToSaveForDeletion() -> [NSObject : AnyObject]! {
    var props = super.propertiesToSaveForDeletion()
    props["timestamp"] = CBLJSON.JSONObjectWithDate(NSDate())
    return props
}

Sometimes you don’t want to save immediately, but you want to get the model’s current state as a JSON object, i.e., the data that would be saved to the document. The propertiesToSave method returns this.

Peer-to-Peer

Two instances of Couchbase Lite can directly sync with each other without a server (peer-to-peer). At least one of them must use the Couchbase Lite Listener library, which enables any Couchbase Lite database to become the remote in a replication by listening on a TCP port and by exposing the standard replication endpoints on that port.

docs listener diagram

It becomes an alternate entry-point into the data store. Another peer can therefore use the URL and port number in the replicator to sync data to and from the database currently listening.

Some typical Listener use cases include:

  • Synchronizing with selected peer devices on the same LAN network.

  • Offline/online: use peer-to-peer in conjunction with Sync Gateway.

Installing the Listener library

Refer to the installation section to install the Listener component. The Couchbase Lite Listener is coupled to Couchbase Lite. Both frameworks should always have the same release version.

Configuring

To begin using the Listener you must create an instance by specifying a manager instance and port number.

let manager = CBLManager.sharedInstance()
self.listener = CBLListener(manager: manager, port: 55000)
self.listener.passwords = ["hello": "pw123"]
self.listener.start(nil)

Make sure to keep a reference to the listener instance in your application otherwise it may be garbage collected and unexpectedly stop listening for incoming HTTP requests. In the example above, the listener instance is initialized as an instance property of the class.

Basic authentication is the recommended approach for protecting database access on the LAN. The listening peer can optionally be initialized with a list of username/password pairs. The peer that intends to run the replication must provide the same username/password http://username:password@hostname:port/dbname.

Discovery

Once you have set up the Listener as an endpoint for other peers to replicate to or from, you can use different discovery methods to browse for peers and subscribe to those of interest.

This section covers two ways to discover peers:

  • Using a QR code to encode the peer’s remote URL.

  • DNS Service Discovery (DNS-SD, aka Bonjour).

QR code

PhotoDrop

PhotoDrop is a P2P sharing app similar to the iOS AirDrop feature that you can use to send photos across devices. The source code is available for iOS and Android. The QR code is used for advertising an adhoc endpoint URL that a sender can scan and send photos to.

DNS-SD

DNS Service Discovery is a standard for discovering services based on a service type. It’s usually coupled with Multicast DNS, which allows devices to broadcast their existence and services on a LAN without requiring a DNS server. These technologies are usually referred to as Bonjour, which is Apple’s name for its implementation, but they’re available under other names on most operating systems. Android calls them Network Service Discovery.

The first step to using Bonjour for peer discovery is to advertise a service with the following properties:

  • Type: Bonjour can be used by many other types of devices on the LAN (printers, scanners, other apps etc). The service type is a way to interact only with peers whose service type is the same.

  • Name: A string to serve as identifier for other peers. It should be unique for each peer. It does not need to be human-readable.

  • Port: The port number the Listener is running on.

  • Metadata: Optional data that will be sent in the advertizment packets (the size limit is around 1.5KB).

To browse for peers on the network, each implementation has an asynchronous API to get notified as peers go online and offline from the network. Given this method of device discovery is platform specific, we recommend to follow the guides below. Once a peer device is discovered and the hostname is resolved, you can start a push and/or pull replication in the same way you would with Sync Gateway.

Resources

Useful resources to work with mDNS include:

  • Bonjour for iOS and Mac applications: The Couchbase Lite SDK exposes part of the Bonjour API for an easier integration. The official documentation for iOS and Mac applications can be found in the NSNetService Programming Guide.

  • NSD for Android applications: The de facto framework for Android is called Network Service Discovery (NSD) and is compatible with Bonjour since Android 4.1. The official guide can be found in the Android NSD guide.

  • JmDNS: Implementation in Java that can be used in Android and Java applications (official repository).

Bonjour browsers

Bonjour browsers are useful to monitor devices broadcasting a particular service on the LAN (OS X Bonjour browser, iOS app, Windows browser)

Connecting

Once the IP address of another device is known you can start replicating data to or from that peer. However, there are some good practice guidelines to follow in order to replicate the changes as they are persisted to a particular node.

Filter functions

It may be desirable to use filtered replications to replicate only the documents of interest to another peer. Filter functions in a peer-to-peer context are executed when the start method on the replication object is called. This is a major difference with the Sync Function available on Sync Gateway that builds the access rules when documents are saved to the Sync Gateway database.

Port allocation

If the port number passed to the Listener is hardcoded, there is a small chance that another application may already be using it. To avoid this scenario, specifying a value of 0 for the port in the Listener constructor will let the TCP stack pick a random available port.

Remote UUID

The replication algorithm keeps track of what was last synchronized with a particular remote database. To identify a remote, it stores a hash of the remote URL http://hostname:port/dbname and other properties such as filters, filter params etc. In the context of peer-to-peer, the IP address will frequently change which will result in a replication starting from scratch and sending over every single document although they may have already been replicated in the past. You can override the method of identifying a remote database using the remoteUUID property of the replicator. If specified, it will be used in place of the remote URL for calculating the remote checkpoint in the replication process.

Security

In addition to using basic authentication, it is also possible to enable SSL over peer-to-peer connections.

SSL for Peer-to-peer

if !listener.setAnonymousSSLIdentityWithLabel("MyApp SSL", error: error) {
   // handle error }

The Listener is now serving SSL using an automatically generated identity.

Wait, Is This Secure?

Yes and no. It encrypts the connection, which is unquestionably much better than not using SSL. But unlike the usual SSL-in-a-browser approach you’re used to, it doesn’t identify the server/listener to the client. The client has to take the cert on faith the first time it connects.

Release Notes

Deprecation notices

The following features are being deprecated in Couchbase Mobile 1.4 and will be unsupported in 2.0.

  • ForestDB

  • Geo queries

The following platforms are being deprecated in Couchbase Mobile 1.4 and will be unsupported in 2.0.

  • iOS 8

1.4.4 release

Performance Improvements
  • #1326 Retry timers should fire immediately when network comes online

Bugs
  • #1898 One shot sync not pulling data properly in background

  • #1912 Peer sync between High Sierra and iOS 11 CBLWarnUntrustedCert error

  • #1971 Assertion : [CBLRemoteRequest createTaskInURLSession:]

  • #1979 SQLITE database is unreadable (err 5)

  • #2130 CBL 1.4.1 Many attachments uploading crashes iOS

  • #2165 Assertion failure in MYFindIdentity

1.4.1 release

Performance Improvements
  • #1648 Purge does not remove row from 'docs' table

  • #1737 View indexing is very slow, due to mis-optimized SQLite query

  • #1751 Push replication becomes slower as local DB grows

Bugs
  • #1354 Deferred pulling of attachments problem

  • #1572 Idle crash [CBLRemoteSession close]

  • #1613 Crash in askDelegateToValidateServerTrust

  • #1622 Error opening!: 23 - when trying to load data from iOS to Apple Watch

  • #1649 Missing role appears to cause continuous push replication to stop [v1.4]

  • #1655 Fatal Exception: NSInternalInconsistencyException [1.4]

  • #1707 Replication Stops working after lots of syncing / lots of time - Too much memory used during replication

  • #1758 Updating a design doc view map function does not take effect

  • #1770 Crash observed while saving documents to DB

  • #1779 IOS App Extension replication gets suspended "prematurely"

  • #1853 CBL_BlobStoreWriter appendData assertion failure

  • #1887 1.4 Encrypting a new database fails. Existing database encrypt fine.

  • #1898 One shot sync not pulling data properly in background

  • #1912 Peer sync between High Sierra and iOS 11 CBLWarnUntrustedCert error

  • #1918 Channel removal potentially disrupts attachments

  • #1921 CBLListener retaining CBL_RunLoopServer so both never get freed.

  • #1923 CBLRemoteSession finishTasksAndInvalidate crash

1.4 release

API change
  • An isDeletion property is now available on the DatabaseChange object to identify if a change is tombstone document.

Performance Improvements
  • #1389 Allow SQLite reads concurrently with writer

  • #1497 Update ForestDB to get improved compaction / space reuse

Enhancements
  • #1538 Make CBLDatabaseChange.isDeletion public?

Bugs
  • #794 "!_changeTracker" assertion failure in -[CBLRestPuller startChangeTracker]

  • #1207 Push replication stops with error 400 bad_request

  • #1243 Replication task missing source or target values

  • #1285 REST API does not allow GET on a db with "/" in its name

  • #1343 Need to close all other db handles before rekeying

  • #1365 Non-continuous push replication gets stuck in kCBLReplicationIdle status

  • #1422 ForestDB crashes frequently in the background because of protection data level

  • #1429 1.3.1-6: crashed EXC_BAD_ACCESS KERN_INVALID_ADDRESS 0x0000000000000000

  • #1442 Collection class properties not propagating from CBLDocument to CBLModel after sync

  • #1443 Handle iOS file protection gracefully when in background

  • #1461 ForestDB: Assertion failure in MYBackgroundMonitor.m:66

  • #1467 Memory leak caused by ref cycle between replicator and CBLRemoteSession

  • #1556 Assertion failed: (_changesTimeout > 0)

  • #1557 Exception caught in CBLDatabase transaction

  • #1558 Not all updates propagating while under load

  • #1568 Attachments failing to push after delete / create (ForestDB)

  • #1579 [NSLock lock]: deadlock when deleting database (ForestDB)

  • #1580 Wrong "reason" response for GET on purged documents

  • #1621 OIDC failing with Grocery Sync when creating new google project
